RALECDatasheet (PDF)
RTT06R04JTP
40mΩ ±5% 333mW 1206 Thick Film Resistor
1206ROHS CompliantActive
RES 40mΩ ±5% 333mW 1206
- Manufacturer
- RALEC
- Manufacturer part #
- RTT06R04JTP
- Store part #
- C159424
- Package / case
- 1206
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,900 in stock
#C159424
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 100+ | ₹0.770 | ₹77.00 |
| 1,000+ | ₹0.627 | ₹627.00 |
| 5,000+ | ₹0.451 | ₹2,255.00 |
| 10,000+ | ₹0.407 | ₹4,070.00 |
| 50,000+ | ₹0.363 | ₹18,150.00 |
| 1,00,000+ | ₹0.341 | ₹34,100.00 |
100 × ₹0.770
₹77.00
excl. GST
₹90.86 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
RTT06R04JTP
₹77.00 for 100 + GST
Specifications
- Resistance
- 40mΩ
- Power(Watts)
- 333mW
- Voltage Rating
- 150V
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Tolerance
- ±5%
- Temperature Coefficient
- ±1000ppm/℃
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 100 (multiples of 100)
- Unit weight
- 0.03 g
Overview
This specification applies to RTT series lead-free, halogen-free, RoHS-compliant thick film chip resistors. The product is intended for general electronic applications.
Applications
- General electronic use
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RTT06R040FTP#C159428RALEC · 1206 | RALEC | 1206 | 4,400 | ₹2.82 · 4,400 in stock | View |
 | 1206W3J040LT5E#C247533UNI-ROYAL · 1206 | UNI-ROYAL | 1206 | 36,100 | ₹0.770 · 36,100 in stock | View |
 | GR1206J0R04T5G00#C49654479GiantOhm · 1206 | GiantOhm | 1206 | 4,300 | ₹0.594 · 4,300 in stock | View |
 | GR1206F0R04T5G00#C49655171GiantOhm · 1206 | GiantOhm | 1206 | 50 | ₹0.990 · 50 in stock | View |
 | HP06W2F400MT5E#C2774938UNI-ROYAL · 1206 | UNI-ROYAL | 1206 | 4,115 | ₹7.98 · 4,115 in stock | View |
