YAGEODatasheet (PDF)
RV0603FR-0710ML
100mW 10MΩ Thick Film Resistor ±1% ±200ppm/℃ 0603 Chip Resistor - Surface Mount RoHS
0603ROHS3 CompliantActive
RES 10MΩ ±1% 100mW 0603
- Manufacturer
- YAGEO
- Manufacturer part #
- RV0603FR-0710ML
- Store part #
- C873271
- Package / case
- 0603
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,800 in stock
#C873271
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.81 | ₹76.20 |
| 200+ | ₹3.00 | ₹600.00 |
| 600+ | ₹2.55 | ₹1,530.00 |
| 5,000+ | ₹2.28 | ₹11,400.00 |
| 10,000+ | ₹2.05 | ₹20,500.00 |
| 20,000+ | ₹1.92 | ₹38,400.00 |
20 × ₹3.81
₹76.20
excl. GST
₹89.92 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
RV0603FR-0710ML
₹76.20 for 20 + GST
Specifications
- Power(Watts)
- 100mW
- Resistance
- 10MΩ
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Tolerance
- ±1%
- Temperature Coefficient
- ±200ppm/℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.023 g
Overview
This specification describes RV0603/0805/1206/2010/2512 high-voltage chip resistors with lead-free terminations, manufactured using thick-film technology.
Applications
- Converters, printer equipment, battery chargers, computers, power supplies, automotive electronics
Key features
- AEC-Q200 certified
- RoHS compliant
- Reduced environmentally hazardous waste
- Enhanced component and device reliability
- No prohibited materials used in product/production process
- Halogen-free epoxy resin
- Moisture Sensitivity Level: MSL I
- IEC 62368-1:2018 safety certificate issued by UL Demko, applicable sizes and resistance ranges as follows:
- 0603: 100KΩ ~ 12MΩ
- 0805: 100KΩ ~ 24MΩ
- 1206: 100KΩ ~ 27MΩ
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RK73H1JTTD1005F#C160010KOA · 0603 | KOA | 0603 | 1,500 | ₹1.36 · 1,500 in stock | View |
 | CR0603-FW-1005ELF#C203213BOURNS · 0603 | BOURNS | 0603 | 14,950 | ₹1.72 · 14,950 in stock | View |
 | RC0603FR-0710ML#C114606YAGEO · 0603 | YAGEO | 0603 | 8,23,600 | ₹0.6615 · 8,23,600 in stock | View |
 | WR06W1005FTL#C163848Walsin · 0603 | Walsin | 0603 | 25,650 | ₹0.4234 · 25,650 in stock | View |
 | AC0603FR-0710ML#C227547YAGEO · 0603 | YAGEO | 0603 | 47,600 | ₹1.28 · 47,600 in stock | View |
