YAGEODatasheet (PDF)
RV0805FR-071M5L
1.5MΩ ±1% 125mW 0805 Thick Film Resistor
0805ROHS3 CompliantActive
RES 1.5MΩ ±1% 125mW 0805
- Manufacturer
- YAGEO
- Manufacturer part #
- RV0805FR-071M5L
- Store part #
- C118025
- Package / case
- 0805
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,900 in stock
#C118025
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹1.26 | ₹63.00 |
| 500+ | ₹0.9923 | ₹496.15 |
| 1,500+ | ₹0.8467 | ₹1,270.05 |
| 5,000+ | ₹0.7409 | ₹3,704.50 |
| 25,000+ | ₹0.6615 | ₹16,537.50 |
| 50,000+ | ₹0.6218 | ₹31,090.00 |
50 × ₹1.26
₹63.00
excl. GST
₹74.34 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
RV0805FR-071M5L
₹63.00 for 50 + GST
Specifications
- Power(Watts)
- 125mW
- Resistance
- 1.5MΩ
- Voltage Rating
- 400V
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±200ppm/℃
- Tolerance
- ±1%
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.03 g
Overview
This specification describes RV0603/0805/1206/2010/2512 high-voltage chip resistors with lead-free terminations, manufactured using thick-film technology.
Applications
- Converters, printer equipment, battery chargers, computers, power supplies, automotive electronics
Key features
- AEC-Q200 certified
- RoHS compliant
- Reduced environmentally hazardous waste
- Enhanced component and device reliability
- No prohibited materials used in product/production process
- Halogen-free epoxy resin
- Moisture Sensitivity Level: MSL I
- IEC 62368-1:2018 safety certificate issued by UL Demko, applicable sizes and resistance ranges as follows:
- 0603: 100KΩ ~ 12MΩ
- 0805: 100KΩ ~ 24MΩ
- 1206: 100KΩ ~ 27MΩ
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RTT051504FTP#C104001RALEC · 0805 | RALEC | 0805 | 50 | ₹0.5557 · 50 in stock | View |
 | AC0805FR-071M5L#C228599YAGEO · 0805 | YAGEO | 0805 | 4,140 | ₹3.19 · 4,140 in stock | View |
 | 0805W8F1504T5E#C26110UNI-ROYAL · 0805 | UNI-ROYAL | 0805 | 22,800 | ₹0.5292 · 22,800 in stock | View |
 | RC0805FR-071M5L#C275642YAGEO · 0805 | YAGEO | 0805 | 10,900 | ₹0.8335 · 10,900 in stock | View |
 | FRC0805F1504TS#C2933325FOJAN · 0805 | FOJAN | 0805 | 62,000 | ₹0.5292 · 62,000 in stock | View |
