YAGEODatasheet (PDF)
RV1206FR-071M5L
1.5MΩ ±1% 250mW 1206 Thick Film Resistor
1206ROHS3 CompliantActive
RES 1.5MΩ ±1% 250mW 1206
- Manufacturer
- YAGEO
- Manufacturer part #
- RV1206FR-071M5L
- Store part #
- C118026
- Package / case
- 1206
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
11,950 in stock
#C118026
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹1.76 | ₹88.00 |
| 500+ | ₹1.44 | ₹720.00 |
| 1,500+ | ₹1.26 | ₹1,890.00 |
| 5,000+ | ₹1.10 | ₹5,500.00 |
| 25,000+ | ₹1.01 | ₹25,250.00 |
| 50,000+ | ₹0.9526 | ₹47,630.00 |
50 × ₹1.76
₹88.00
excl. GST
₹103.84 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
RV1206FR-071M5L
₹88.00 for 50 + GST
Specifications
- Resistance
- 1.5MΩ
- Power(Watts)
- 250mW
- Voltage Rating
- 500V
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±200ppm/℃
- Tolerance
- ±1%
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.03 g
Overview
This specification describes RV0603/0805/1206/2010/2512 high-voltage chip resistors with lead-free terminations, manufactured using thick-film technology.
Applications
- Converters, printer equipment, battery chargers, computers, power supplies, automotive electronics
Key features
- AEC-Q200 certified
- RoHS compliant
- Reduced environmentally hazardous waste
- Enhanced component and device reliability
- No prohibited materials used in product/production process
- Halogen-free epoxy resin
- Moisture Sensitivity Level: MSL I
- IEC 62368-1:2018 safety certificate issued by UL Demko, applicable sizes and resistance ranges as follows:
- 0603: 100KΩ ~ 12MΩ
- 0805: 100KΩ ~ 24MΩ
- 1206: 100KΩ ~ 27MΩ
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | CR1206-FW-1504ELF#C205031BOURNS · 1206 | BOURNS | 1206 | 7,020 | ₹3.86 · 7,020 in stock | View |
 | FRV1206F1504TS#C54102308FOJAN · 1206 | FOJAN | 1206 | 7,800 | ₹3.49 · 7,800 in stock | View |
 | KTR18EZPF1504#C510125ROHM · 1206 | ROHM | 1206 | 560 | ₹2.96 · 560 in stock | View |
| ERJ-PM8F1504V#C6244159PANASONIC · 1206 | PANASONIC | 1206 | 15 | ₹11.39 · 15 in stock | View | |
 | RC1206FR-071M5L#C137367YAGEO · 1206 | YAGEO | 1206 | 82,850 | ₹1.31 · 82,850 in stock | View |
