YAGEODatasheet (PDF)
RV1206FR-07510KL
250mW 510kΩ 500V Thick Film Resistor ±1% ±200ppm/℃ 1206 Chip Resistor - Surface Mount RoHS
1206ROHS3 CompliantActive
RES 510kΩ ±1% 250mW 1206
- Manufacturer
- YAGEO
- Manufacturer part #
- RV1206FR-07510KL
- Store part #
- C873572
- Package / case
- 1206
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,280 in stock
#C873572
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.33 | ₹66.60 |
| 200+ | ₹2.74 | ₹548.00 |
| 600+ | ₹2.42 | ₹1,452.00 |
| 5,000+ | ₹2.22 | ₹11,100.00 |
| 10,000+ | ₹2.05 | ₹20,500.00 |
| 20,000+ | ₹1.96 | ₹39,200.00 |
20 × ₹3.33
₹66.60
excl. GST
₹78.59 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
RV1206FR-07510KL
₹66.60 for 20 + GST
Specifications
- Power(Watts)
- 250mW
- Resistance
- 510kΩ
- Voltage Rating
- 500V
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Tolerance
- ±1%
- Temperature Coefficient
- ±200ppm/℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.03 g
Overview
This specification describes RV0603/0805/1206/2010/2512 high-voltage chip resistors with lead-free terminations, manufactured using thick-film technology.
Applications
- Converters, printer equipment, battery chargers, computers, power supplies, automotive electronics
Key features
- AEC-Q200 certified
- RoHS compliant
- Reduced environmentally hazardous waste
- Enhanced component and device reliability
- No prohibited materials used in product/production process
- Halogen-free epoxy resin
- Moisture Sensitivity Level: MSL I
- IEC 62368-1:2018 safety certificate issued by UL Demko, applicable sizes and resistance ranges as follows:
- 0603: 100KΩ ~ 12MΩ
- 0805: 100KΩ ~ 24MΩ
- 1206: 100KΩ ~ 27MΩ
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | HV06W4F5103T5E#C414783UNI-ROYAL · 1206 | UNI-ROYAL | 1206 | 3,050 | ₹1.27 · 3,050 in stock | View |
 | RC1206FR-07510KL#C137257YAGEO · 1206 | YAGEO | 1206 | 34,600 | ₹0.7012 · 34,600 in stock | View |
 | AC1206FR-07510KL#C138249YAGEO · 1206 | YAGEO | 1206 | 100 | ₹1.19 · 100 in stock | View |
 | WR12X5103FTL#C168554Walsin · 1206 | Walsin | 1206 | 2,500 | ₹1.65 · 2,500 in stock | View |
 | 1206W4F5103T5E#C17990UNI-ROYAL · 1206 | UNI-ROYAL | 1206 | 3,04,600 | ₹0.5821 · 3,04,600 in stock | View |
