TECH PUBLICDatasheet (PDF)
SMF24CA
38.9VC Clamp 5.1A@10/1000us Ipp SOD-123FL
SOD-123FLRoHSActive
24VWM 38.9VC SOD-123FL
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SMF24CA
- Store part #
- C42370537
- Package / case
- SOD-123FL
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,620 in stock
#C42370537
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.07 | ₹61.40 |
| 200+ | ₹2.42 | ₹484.00 |
| 600+ | ₹2.06 | ₹1,236.00 |
| 2,000+ | ₹1.85 | ₹3,700.00 |
| 10,000+ | ₹1.65 | ₹16,500.00 |
| 20,000+ | ₹1.56 | ₹31,200.00 |
20 × ₹3.07
₹61.40
excl. GST
₹72.45 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMF24CA
₹61.40 for 20 + GST
Specifications
- Clamping Voltage
- 38.9V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 5.1A@10/1000us
- Peak Pulse Power Dissipation (Ppp)
- 200W@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 29.5V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 24V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.042 g
Overview
Applications
- Personal digital assistants (PDA)
- Cellular handsets & Accessories
- Handhelds and notebooks
- Portable instrumentation
Key features
- Peak power disspation 200W@10×1000 us Pluse
- Low incremental surge resistance
- Excellent clamping capability
- Fast response time
- Low leakage current
- Halogen free and RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SMFJ24CA#C42370548TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 2,980 | ₹4.14 · 2,980 in stock | View |
 | TPSMF24CA#C42370584TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 1,540 | ₹4.21 · 1,540 in stock | View |
 | SJD12C24L01#C54780907TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 1,000 | ₹3.98 · 1,000 in stock | View |
 | SMF26CA#C42370540TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 7,080 | ₹3.00 · 7,080 in stock | View |
 | TPSMF26CA#C42370586TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 2,340 | ₹3.65 · 2,340 in stock | View |
