SN74HC373PWR-JSM
D Latch 2V~6V 8 38ns TSSOP-20 Latches RoHS
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,880 in stock
#C53114330
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.70 | ₹113.50 |
| 50+ | ₹17.98 | ₹899.00 |
| 150+ | ₹15.96 | ₹2,394.00 |
| 500+ | ₹13.44 | ₹6,720.00 |
| 2,500+ | ₹12.32 | ₹30,800.00 |
| 4,000+ | ₹11.64 | ₹46,560.00 |
5 × ₹22.70
₹113.50
excl. GST
₹133.93 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
SN74HC373PWR-JSM
₹113.50 for 5 + GST
Specifications
- Quiescent Current
- 8uA
- Logic Type
- D Latch
- Series
- 74HC
- Voltage - Supply
- 2V~6V
- Operating Temperature
- -40℃~+125℃
- Output Type
- Tri-State
- Setup Time
- 9ns
- Number of Gates
- 8
- Hold Time
- 5ns
- Propagation Delay
- 38ns
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.199 g
Overview
The 74HC/HCT373 is an 8-bit D-type latch with three-state outputs. The device features a latch enable (LE) and an output enable (OE) input. When LE is HIGH, data at the inputs enters the latches; the latches are transparent and the outputs change with their corresponding D inputs. When LE is LOW, the latches store the input information that was present one setup time prior to the falling edge of LE. When OE is HIGH, the outputs are in a high-impedance state. The OE operation does not affect the internal state of the latches. Input clamping diodes are provided, enabling the use of current-limiting resistors to interface inputs to voltages exceeding VCC.
Key features
- 74HC373: CMOS-level input
- 74HCT373: TTL-level input
- Three-state non-inverting outputs for bus applications
- Common three-state output enable input
- Functionally equivalent to 74HC/HCT563 and 74HC/HCT573
- Operating temperature range: -40℃ ~ +125℃
- Package types: DIP20, SOP20, TSSOP20
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| SN74HC573PW-JSM#C53114280JSMSEMI · TSSOP-20 | JSMSEMI | TSSOP-20 | 1,145 | ₹20.15 · 1,145 in stock | View | |
