lingxingic

SN74LVC2G14DC(LX)

1.65V~5.5V 1 2 SOT-363 Flip Flops

SOT-363RoHSActive

Dual Inverter Schmitt Trigger

Manufacturer: lingxingic
Manufacturer part #: SN74LVC2G14DC(LX)
Store part #: C22469938
Package / case: SOT-363
Category: Flip Flops
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,070 in stock

#C22469938

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
10+	₹7.21	₹72.10
100+	₹5.70	₹570.00
300+	₹4.95	₹1,485.00
3,000+	₹4.38	₹13,140.00
6,000+	₹3.93	₹23,580.00
9,000+	₹3.70	₹33,300.00

Quantity (min 10, multiples of 10)

10 × ₹7.21

₹72.10

excl. GST

₹85.08 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

SN74LVC2G14DC(LX)

₹72.10 for 10 + GST

Specifications

Voltage - Supply: 1.65V~5.5V
Number of Bits per Element: 1
Output Type: Push-Pull
Operating Temperature: -40℃~+125℃
Series: 74LVC Series
Current - Output High(IOH): 24mA
Number of Elements: 2
Current - Output Low(IOL): 24mA
Quiescent Current: 4uA
Propagation Delay: 7ns@5.5V,50pF;8ns@3.3V,50pF;9ns@2.7V,50pF;10ns@2.3V,30pF;14ns@1.8V,30pF

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.043 g

Overview

The SN74LVC2G14 provides two inverting buffers with Schmitt-trigger input. It is capable of transforming slowly changing input signals into sharply defined, jitter-free output signals. The inputs can be driven from either 3.3V or 5V devices. This feature allows the use of this device in a mixed 3.3V and 5V environment. Schmitt-trigger action at the inputs makes the circuit tolerant of slower input rise and fall time.
