VISHAYDatasheet (PDF)
SS15-E3/61T
Diode 1 Independent 50V 1A Surface Mount DO-214AC
DO-214ACROHS3 CompliantActive
DIODE SCHOTTKY 50V DO-214AC
- Manufacturer
- VISHAY
- Manufacturer part #
- SS15-E3/61T
- Store part #
- C3151634
- Package / case
- DO-214AC
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
405 in stock
#C3151634
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹32.63 | ₹163.15 |
| 50+ | ₹26.38 | ₹1,319.00 |
| 150+ | ₹23.69 | ₹3,553.50 |
| 500+ | ₹20.36 | ₹10,180.00 |
| 1,800+ | ₹16.82 | ₹30,276.00 |
| 5,400+ | ₹15.93 | ₹86,022.00 |
5 × ₹32.63
₹163.15
excl. GST
₹192.52 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,800 per reel
SS15-E3/61T
₹163.15 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -65℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 50V
- Voltage - Forward(Vf@If)
- 750mV@1A
- Reverse Leakage Current (Ir)
- 200uA@50V
- Non-Repetitive Peak Forward Surge Current
- 40A
- Current - Rectified
- 1A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,800 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.092 g
Overview
Applications
- For use in low voltage, high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
Key features
- Low profile package
- Ideal for automated placement
- Guardring for overvoltage protection
- Low power losses, high efficiency
- Low forward voltage drop
- High surge capability
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified available
- Automotive ordering code: base P/NHE3 or P/NHM3
- Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SS16-E3/61T#C183023VISHAY · SMA(DO-214AC) | VISHAY | SMA(DO-214AC) | 46,430 | ₹12.86 · 46,430 in stock | View |
 | MBRA160T3G(MS)#C22399570MSKSEMI · SMA | MSKSEMI | SMA | 1,840 | ₹12.04 · 1,840 in stock | View |
 | SS16HE3_B/H#C266798VISHAY · SMA(DO-214AC) | VISHAY | SMA(DO-214AC) | 3,645 | ₹21.83 · 3,645 in stock | View |
 | SS26SHE3_B/H#C511359VISHAY · SMA(DO-214AC) | VISHAY | SMA(DO-214AC) | 16,820 | ₹16.42 · 16,820 in stock | View |
 | SS16-E3/5AT#C511401VISHAY · SMA(DO-214AC) | VISHAY | SMA(DO-214AC) | 5,995 | ₹20.02 · 5,995 in stock | View |
