Silergy

SY7011AABC

Boost Switching Regulator IC Adjustable 1.8V~5.5V 1 Output 1A SOT23-6

SOT23-6RoHSActive

High Efficiency 700nA Ultra Low IQ 1A Synchronous Boost Converter

Manufacturer: Silergy
Manufacturer part #: SY7011AABC
Store part #: C7427427
Package / case: SOT23-6
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,805 in stock

#C7427427

Stock & price checked 31 h ago

Quantity	Unit price	Pack price
5+	₹49.16	₹245.80
50+	₹39.19	₹1,959.50
150+	₹34.91	₹5,236.50
500+	₹26.86	₹13,430.00
3,000+	₹24.48	₹73,440.00
6,000+	₹23.06	₹1,38,360.00

Quantity (min 5, multiples of 5)

5 × ₹49.16

₹245.80

excl. GST

₹290.04 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

SY7011AABC

₹245.80 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+125℃
Function: Boost
Number of Outputs: 1
Frequency - Switching: 1MHz
Features: Load disconnect
Output Type: Adjustable
Topology: Boost
Operating Voltage: 850mV~5.5V
Switch tube (built-in/external): Built-in
Output Current: 1A
Output Voltage: 1.8V~5.5V
Quiescent Current: 700nA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.062 g

Overview

Applications

All Single Cell Li or Dual Cell Battery Operated Products as MP-3 Player, PDAs, and Other Portable Equipment

Key features

0.85V Minimum Input Voltage
Adjustable Output Voltage From 1.8V to 5.5V
Min 1A Valley Current Limit
700nA Low Quiescent Current
5V/0.5A Output Capability
Load Disconnect During Shutdown
Low RDS(ON) (Main Switch/Synchronous Switch) at 3.3V Output: 120/200mΩ
Output OVP
RoHS Compliant and Halogen Free
Auto Bypass Mode When ΔVIN ≥ VOUT
Compact Package SOT23-6

Alternatives

Similar parts — check the datasheet before substituting.

Part		Manufacturer	Package	Stock	Price from (excl. GST)	Action
	SY7072AABC#C22386819Silergy · SOT-23-6	Silergy	SOT-23-6	26,934	₹68.52 · 26,934 in stock	View
