TC74HC04AF(EL,F)
2V~6V 13ns@6V,50pF 1uA 6 SOIC-14-175mil Gates and Inverters RoHS
SOIC-14-175milROHS CompliantActive
Hex Inverter
- Manufacturer
- TOSHIBA
- Manufacturer part #
- TC74HC04AF(EL,F)
- Store part #
- C5381646
- Package / case
- SOIC-14-175mil
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,042 in stock
#C5381646
Stock & price checked 43 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹113.43 | ₹113.43 |
| 10+ | ₹90.63 | ₹906.30 |
| 30+ | ₹79.10 | ₹2,373.00 |
| 100+ | ₹67.80 | ₹6,780.00 |
| 500+ | ₹61.07 | ₹30,535.00 |
| 1,000+ | ₹57.59 | ₹57,590.00 |
1 × ₹113.43
₹113.43
excl. GST
₹133.85 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
TC74HC04AF(EL,F)
₹113.43 for 1 + GST
Specifications
- Logic Family
- 74HC
- Voltage - Supply
- 2V~6V
- Propagation Delay
- 13ns@6V,50pF
- Input Logic Level - High
- 1.5V~4.2V
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - Low
- 500mV~1.8V
- Quiescent Current(Iq)
- 1uA
- Number of Channels
- 6
- Current - Output High(IOH)
- 5.2mA
- Current - Output Low(IOL)
- 5.2mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.289 g
Overview
The TC74HC04A is a high speed CMOS INVERTER fabricated with silicon gate C²MOS technology. It achieves the high speed operation similar to equivalent LSTTL while maintaining the CMOS low power dissipation. The internal circuit is composed of 3 stages, including buffered output, which provide high noise immunity and stable output. All inputs are equipped with protection circuits against satic discharge or transient excess voltage.
Key features
- High speed: tpd = 6 ns (typ.) at VCC = 5 V
- Low power dissipation: Icc = 1 μA (max) at Ta = 25℃
- High noise immunity: VNI H = VNI L = 28% VCC (min)
- Output drive capability: 10 LSTTL loads
- Symmetrical output impedance: IIOHI = IOL = 4 mA (min)
- Balanced propagation delays: tpLH ≈ tpHL
- Wide operating voltage range: VCC (opr) = 2 to 6 V
- Pin and function compatible with 74LS04
