TC7SH04FU-TP
2V~5.5V 700ps@5V,15pF 10uA 1 SOT353 Gates and Inverters
SOT353RoHSActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- TC7SH04FU-TP
- Store part #
- C54195010
- Package / case
- SOT353
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,860 in stock
#C54195010
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.34 | ₹63.40 |
| 100+ | ₹5.00 | ₹500.00 |
| 300+ | ₹4.33 | ₹1,299.00 |
| 3,000+ | ₹3.82 | ₹11,460.00 |
| 6,000+ | ₹3.43 | ₹20,580.00 |
| 9,000+ | ₹3.23 | ₹29,070.00 |
10 × ₹6.34
₹63.40
excl. GST
₹74.81 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TC7SH04FU-TP
₹63.40 for 10 + GST
Specifications
- Logic Family
- TC7SH
- Voltage - Supply
- 2V~5.5V
- Output Logic Level - Low
- 450mV;300mV;400mV;550mV
- Propagation Delay
- 700ps@5V,15pF
- Input Logic Level - High
- 1.7V;2V
- Input Logic Level - Low
- 700mV;800mV
- Operating Temperature
- -40℃~+125℃
- Output Logic Level - High
- 1.2V;1.9V;2.4V;2.3V;3.8V
- Quiescent Current(Iq)
- 10uA
- Number of Channels
- 1
- Current - Output High(IOH)
- 32mA
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.028 g
Overview
TC7SH04 is a single inverter gate. The device is designed for operation with Vcc ranging from 2V to 5.5V and can be driven by 3.3V or 5V devices. This feature allows these devices to be used as translators in mixed 3.3V and 5V environments. The TC7SH04 performs the Boolean function Y = A in positive logic. This CMOS device maintains low quiescent power consumption across a wide Vcc operating range while providing high output drive capability. The TC7SH04 is available in SOT23-5 and SOT353 packages.
Applications
- Active Noise Cancellation (ANC)
- Blood Pressure Monitor
- Embedded PC
- SSD: Client and Enterprise
- TV: LCD/Digital and HDTV
- Tablet: Enterprise
- Video Analytics: Server
- Wireless Headset, Keyboard and Mouse
- Power Supply: Telecom/Server AC/DC Controller
Key features
- Wide supply voltage range: 2V to 5.5V
- Maximum propagation delay of 3.3ns at Vcc = 3.3V
- Low power consumption, 10μA (maximum Icc)
- Output drive current ±24mA at Vcc = 3.3V
- Latch-up performance exceeds 100mA per JESD 78 Class II
- ESD protection exceeds JESD 22
- 2000V Human Body Model (A114-A)
- 1000V Charged Device Model (C101)
- Operating temperature range: -40°C to 125°C
- Available packages: SOT23-5 and SOT353
