TP132LC12S3L
Linear Voltage Regulator IC Positive Fixed 1 Output 300mA SOT-23-3L
SOT-23-3LRoHSActive
Ultra Low Consumption CMos Voltage Regulator
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- TP132LC12S3L
- Store part #
- C48586703
- Package / case
- SOT-23-3L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,490 in stock
#C48586703
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.07 | ₹60.70 |
| 100+ | ₹4.83 | ₹483.00 |
| 300+ | ₹4.21 | ₹1,263.00 |
| 3,000+ | ₹3.73 | ₹11,190.00 |
| 6,000+ | ₹3.36 | ₹20,160.00 |
| 9,000+ | ₹3.18 | ₹28,620.00 |
10 × ₹6.07
₹60.70
excl. GST
₹71.63 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TP132LC12S3L
₹60.70 for 10 + GST
Specifications
- Output Voltage
- 1.2V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+85℃@(Ta)
- Supply Current (Iq)
- 800nA
- Output Configuration
- Positive
- Output Current
- 300mA
- Operating Voltage
- 7V
- Features
- Enable control;Output discharge
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.036 g
Overview
Applications
- Portable consumer devices
- Radio control systems
- Wireless communication devices
- Ultra-low-power microcontrollers
Key features
- Quiescent current 0.8µA (typical)
- Output accuracy ±2%
- Output current 300mA
- Compact packages: DFN1X1-4, SOT23-5, SOT23-3L, SOT23
