MICROCHIPDatasheet (PDF)
TP5322N8-G
900mW 220V 700mA 8Ω@10V 1 P-Channel P-Channel SOT-89-3 Single FETs, MOSFETs RoHS
SOT-89-3ROHS3 CompliantActive
- Manufacturer
- MICROCHIP
- Manufacturer part #
- TP5322N8-G
- Store part #
- C629210
- Package / case
- SOT-89-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6 in stock
#C629210
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹287.59 | ₹287.59 |
| 10+ | ₹282.87 | ₹2,828.70 |
| 30+ | ₹279.85 | ₹8,395.50 |
| 100+ | ₹276.85 | ₹27,685.00 |
1 × ₹287.59
₹287.59
excl. GST
₹339.36 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
TP5322N8-G
₹287.59 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 45pF
- Ciss-Input Capacitance
- 110pF
- Pd - Power Dissipation
- 900mW
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 220V
- Current - Continuous Drain(Id)
- 700mA
- Reverse Transfer Capacitance (Crss)
- 20pF
- RDS(on)
- 8Ω@10V
- Number
- 1 P-Channel
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 2.4V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.52 g
Overview
The TP5322 low-threshold Enhancement-mode (normally-off) transistor uses a vertical DMOS structure and a well-proven silicon-gate manufacturing process. This combination produces a device with the power handling capabilities of bipolar transistors and the high input impedance and positive temperature coefficient inherent in MOS devices. Characteristic of all MOS structures, this device is free from thermal runaway and thermally induced secondary breakdown. Microchip’s vertical DMOS FETs are ideally suited for a wide range of switching and amplifying applications where very low threshold voltage, high breakdown voltage, high input impedance, low input capacitance, and fast switching speeds are desired.
Applications
- Logic-Level Interfaces (Ideal for TTL and CMOS)
- Battery-Operated Systems
- Photovoltaic Drives
- Analog Switches
- General Purpose Line Drivers
- Telecommunication Switches
Key features
- –2.4V Maximum Low Threshold
- High Input Impedance
- 110 pF Maximum Low Input Capacitance
- Fast Switching Speeds
- Low On-Resistance
- Free from Secondary Breakdown
- Low Input and Output Leakage
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TP2540N8-G#C629209MICROCHIP · SOT-89 | MICROCHIP | SOT-89 | 11 | ₹446.43 · 11 in stock | View |
 | TP2522N8-G#C629207MICROCHIP · SOT-89-3 | MICROCHIP | SOT-89-3 | 10 | ₹755.51 · 10 in stock | View |
 | HSK2P25#C22359224HUASHUO · SOT-89 | HUASHUO | SOT-89 | 275 | ₹39.78 · 275 in stock | View |
 | TP2520N8-G#C629206MICROCHIP · SOT-89-3 | MICROCHIP | SOT-89-3 | 2 | ₹670.40 · 2 in stock | View |
 | TP2435N8-G#C629203MICROCHIP · SOT-89-3 | MICROCHIP | SOT-89-3 | On request | ₹617.09 · 0 in stock | View |
