TPD1S514-1YZR

Protection IC 3.5A DSBGA-12 Power Management - Specialized RoHS

DSBGA-12ROHS3 CompliantActive

USB Charger Over Voltage, Surge and ESD Protection for VBus PIN

Manufacturer: TI
Manufacturer part #: TPD1S514-1YZR
Store part #: C140247
Package / case: DSBGA-12
Category: Power Management - Specialized
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,000 in stock

#C140247

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹92.60	₹92.60
10+	₹78.31	₹783.10
30+	₹68.18	₹2,045.40
100+	₹59.86	₹5,986.00
500+	₹57.33	₹28,665.00
1,000+	₹55.70	₹55,700.00

Quantity (min 1)

1 × ₹92.60

₹92.60

excl. GST

₹109.27 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

TPD1S514-1YZR

₹92.60 for 1 + GST

Specifications

Type: Protection IC
Features: Overvoltage protection;Under-voltage lockout;Soft-start
Operating Temperature: -40℃~+85℃
0V Battery Charge: Not supported
Quiescent Current: 150uA
Charge Current - Max: 3.5A
Voltage - Supply: 3.5V~5.9V

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.036 g

Overview

The TPD1S514 Family consists of single-chip protection solutions for 5-V, 9-V or 12-V USB VBUS lines, or other power buses. The bidirectional nFET switch ensures safe current flow in both charging and host mode while protecting the internal system circuits from any over voltage condition at the VBUS_CON pin. On the VBUS_CON pin, this device can handle over voltage protection up to 30-V DC. After the EN pin toggles low, any device in the TPD1S514 Family waits 20 ms before turning ON the nFET through a soft start delay. Typical application interfaces for the TPD1S514 Family are VBUS lines in USB connectors typically found in cell phones, tablets, eBooks, and portable media players. The TPD1S514 Family can also be applied to any system using an interface for a 5-V, 9- V, or 12-V power rail.

Applications

Cell Phones
Tablets
eBook
Portable Media Players 5-V, 9-V, and 12-V Power Rails

Key features

Over Voltage Protection at VBUS_CON up to 30-V DC
Precision OVP (< ± 1% Tolerance)
Low RON nFET Switch Supports Host and Charging Mode
Dedicated VBUS_POWER Pin Offers Flexible Power up Options Under Dead Battery Condition
Transient Protection for VBUS Line: IEC 61000-4-2 Contact Discharge ±15 kV, IEC 61000-4-2 Air Gap Discharge ±15 kV, IEC 61000-4-5 Open Circuit Voltage 100 V, Precision Clamp Circuit Limits the VBUS_SYS Voltage < VOVP
USB Inrush Current Compliant Thermal Shutdown (TSD) Feature
