HANSCHIP semiconductor

UC3843DRG

1A 47kHz~57kHz 1W 7.6V~30V SOP-8 AC DC Converters, Offline Switchers RoHS

SOP-8ROHS CompliantActive

UC284x/UC384x series PWM controllers (suitable for offline power supplies and DC-DC converters)

Manufacturer: HANSCHIP semiconductor
Manufacturer part #: UC3843DRG
Store part #: C19723748
Package / case: SOP-8
Category: AC DC Converters, Offline Switchers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,370 in stock

#C19723748

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
5+	₹16.70	₹83.50
50+	₹13.20	₹660.00
150+	₹11.46	₹1,719.00
500+	₹10.15	₹5,075.00
2,500+	₹9.09	₹22,725.00
5,000+	₹8.57	₹42,850.00

Quantity (min 5, multiples of 5)

5 × ₹16.70

₹83.50

excl. GST

₹98.53 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

UC3843DRG

₹83.50 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: 0℃~+70℃
Output Current: 1A
Frequency - Switching: 47kHz~57kHz
Pd - Power Dissipation: 1W
Voltage - Supply: 7.6V~30V
Features: Under-voltage lockout;Under Voltage Protection;Over Current Protection
Duty Cycle(Max): 97%
Working Mode: PWM Modulation

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.248 g

Overview

The UC284x and UC384x are fixed frequency current mode PWM controller. They are specially designed for OFF Line and DC to DC converter applications with a minimal external components. Internally implemented circuits include a trimmed oscillator for precise duty cycle control, a temperature compensated reference, high gain error amplifier, current sensing comparator, and a high current totem pole output ideally suited for driving a power MOSFET. Protection circuitry includes built under voltage lockout and current limiting. The UC2842/44, UC3842/44 have UVLO thresholds of 16V (on) and 10V (off). The corresponding thresholds for the UC2843/45, UC3843/45 are 8.4V (on) and 7.6V (off). The UC2842/43, UC3842/43 can operate within 100% duty cycle. The UC2844/45, UC3844/45 can operate within 50% duty cycle. The UC2842/44/44/45 is characterized for operation from TA = -40°C to 85°C. The UC3842/43/44/45 is characterized for operation from TA = 0°C to 70°C.
