V2P22L-M3/H
Diode 1 Independent 200V 2A Surface Mount DO-220AA(SMP)
DO-220AA(SMP)ROHS3 CompliantActive
DIODE SCHOTTKY 200V DO-220AA(SMP)
- Manufacturer
- VISHAY
- Manufacturer part #
- V2P22L-M3/H
- Store part #
- C3757426
- Package / case
- DO-220AA(SMP)
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
45 in stock
#C3757426
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹29.40 | ₹147.00 |
| 50+ | ₹28.83 | ₹1,441.50 |
| 150+ | ₹28.44 | ₹4,266.00 |
| 500+ | ₹28.07 | ₹14,035.00 |
5 × ₹29.40
₹147.00
excl. GST
₹173.46 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
V2P22L-M3/H
₹147.00 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -40℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 200V
- Voltage - Forward(Vf@If)
- 760mV@1A
- Reverse Leakage Current (Ir)
- 40uA@200V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.048 g
Overview
Applications
- For use in low voltage, high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
Key features
- Low profile package
- Trench MOS Schottky technology
- Low power losses, high efficiency
- Low forward voltage drop
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified available
- Automotive ordering code; base P/N HM3
- Material categorization: for definitions of compliance please see www.vishay.com/doc?299912
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | V2P22LHM3/H#C3759527VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | 395 | ₹40.31 · 395 in stock | View |
| V2P22L-M3/I#C3757812VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | On request | ₹15.19 · 0 in stock | View | |
| V3P22-M3/I#C3757416VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | On request | ₹18.10 · 0 in stock | View | |
| V3P22-M3/H#C3759021VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | On request | ₹35.77 · 0 in stock | View | |
