VN1160TR-E

- ST’s offer of fully-protected automotive high-side switches (HSDs) is the broadest in the market. Having an unmatched range of packages, on-resistances, number of output channels and diagnostic options, HSDs are able to drive resistive, inductive and capacitive grounded loads in compliance with the stringent safety and reliability requirements of automotive applications. - Based on its proprietary VIPower™ technology, ST’s high-side switches have 3 V and 5 V CMOS compatible I/Os for control and vertical mosfet for the power outputs, and are the perfect companions for a microcontroller. - The M0-7 series is the ultimate VIPower product generation, born to deliver the widest range of on-state resistance and number of channels with full pin-to-pin compatibility in the smallest packages. - The M0‑5 series is the largest family of VIPower high-side switches developed to drive any kind of automotive load. - ST’s VIPowerTM Zero series offers innovative and high-performance protected switches for driving high power applications. This series covers today’s growing demand for intelligent power devices able to drive and protect high-power loads such as those used in high-current fan motors, heaters and protected battery lines in electrical power distribution systems. - The new L99DZ1x0 Family brings higher performances in the Door Zone Applications: novel devices embed, in the same package, Power management power supply functionality (including various standby modes, as well as LIN and HS CAN physical communication layers) together with all the Actuators for main Door loads. - Fully-protected, low-side switches safely drive resistive, inductive and capacitive loads with one terminal connected to the battery, in compliance with the stringent safety and reliability requirements of automotive applications. - ST’s low-side switches offer a power output in addition to control and diagnostic function in one single chip and are available with both single - and dual-channel options. - Built in the VIPower M0‑5 technology, the OMNIFET III series addresses a broad range of applications in tiny packages, delivering protection and diagnostic features.

Applications

• Car body applications
• Door Zone Applications

Key features

• Complete family of low on-resistance protected solutions
• Output re-activation during reverse polarity
• State-of-the-art and adaptable protection strategy
• Sophisticated diagnostics
• Cold-cranking capability (device option)
• Device option with extended diagnostics capability cover a wide range of load currents
• Best-in-class EMI performance, short-circuit protection and robustness
• Lower quiescent current
• Precise load-current, battery voltage and device temperature analog feedback
• Extended load compatibility due to higher current limitation
• Instantaneous diagnosis of short‑to‑ground or overload
• OFF-state diagnosis for the analog current sense option (‘E’ types)
