W25Q128DR-TD
FLASH - NOR Memory IC 128Mbit SPI SOP-8-208mil
128MBIT SPI NOR FLASH
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,037 in stock
#C49211308
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹332.47 | ₹332.47 |
| 10+ | ₹278.36 | ₹2,783.60 |
| 30+ | ₹244.69 | ₹7,340.70 |
| 100+ | ₹210.13 | ₹21,013.00 |
| 500+ | ₹194.48 | ₹97,240.00 |
| 1,000+ | ₹187.54 | ₹1,87,540.00 |
1 × ₹332.47
₹332.47
excl. GST
₹392.31 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
W25Q128DR-TD
₹332.47 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Write enable latch;Power-on reset;Hardware write protection;Software write protection;Absolute write protection
- Memory Size
- 128Mbit
- Voltage - Supply
- 2.7V~3.6V
- Program / Erase Cycles
- 100,000 cycles
- Clock Frequency
- 120MHz
- Data Retention - TDR (Year)
- 20 Years
- Block Erase Time(tBE)
- 400ms
- Page Programming Time (Tpp)
- 700us
- Standby Supply Current
- 2uA
- Interface
- SPI
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.209 g
Overview
The 25Q128- TD is 128M- bit Serial Peripheral Interface (SPI) Flash memory, and supports the Dual/Quad SPI: Serial Clock, Chip Select, Serial Data I/O0 (SI), I/O1 (SO), I/O2 (WP), and I/O3 (/HOLD). The Dual I/O data is transferred with speed of 216Mbits/s and the Quad I/O & Quad output data is transferred with speed of 432Mbits/s. The device uses a single low voltage power supply, ranging from 2.7 Volt to 3.6 Volt. Additionally, the device supports JEDEC standard manufacturer and device ID and three 1024bytes Security Registers.
