waferbest

WB2967J

1 2.8A High Side Switch SOT-23-3L Power Distribution Switches, Load Drivers

SOT-23-3LRoHSActive

Manufacturer: waferbest
Manufacturer part #: WB2967J
Store part #: C51933790
Package / case: SOT-23-3L
Category: Power Distribution Switches, Load Drivers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

6,315 in stock

#C51933790

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹10.15	₹50.75
50+	₹8.07	₹403.50
150+	₹7.03	₹1,054.50
500+	₹6.24	₹3,120.00
3,000+	₹5.61	₹16,830.00
6,000+	₹5.31	₹31,860.00

Quantity (min 5, multiples of 5)

5 × ₹10.15

₹50.75

excl. GST

₹59.89 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

WB2967J

₹50.75 for 5 + GST

Specifications

Operating Temperature: -40℃~+85℃
Features: Overcurrent Protection;Short-Circuit Protection;Over temperature protection;Overvoltage protection;Under-voltage lockout;Integrated charge pump
number of channels: 1
Maximum Continuous Current: 2.8A
RDS(on): 130mΩ
Operating Voltage: 3.6V~32V
Type: High Side Switch

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.049 g

Overview

WB2967J is a 32V overvoltage protection device with a 130mΩ on-resistance. It features an internal overvoltage threshold of 6.2V and an overcurrent threshold of 2.8A. The device integrates a charge pump, power MOSFET, voltage reference, gate driver, and logic & protection circuitry, delivering an extremely fast response to input surges — shutting off the switch within 0.1μs while withstanding voltage transients up to 20V. The chip is offered in a SOT23-3L package.
