hengjiaxing

XC6206-3.0NR

3V Positive Fixed SOT-23 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS

SOT-23ROHS CompliantActive

300mA Low Power LDO

Manufacturer: hengjiaxing
Manufacturer part #: XC6206-3.0NR
Store part #: C2984873
Package / case: SOT-23
Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,150 in stock

#C2984873

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
50+	₹1.85	₹92.50
500+	₹1.44	₹720.00
3,000+	₹1.20	₹3,600.00
6,000+	₹1.07	₹6,420.00
24,000+	₹0.9526	₹22,862.40
51,000+	₹0.8864	₹45,206.40

Quantity (min 50, multiples of 50)

50 × ₹1.85

₹92.50

excl. GST

₹109.15 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

XC6206-3.0NR

₹92.50 for 50 + GST

Specifications

Output Voltage: 3V
Number of Outputs: 1
Operating Temperature: -40℃~+85℃
Supply Current (Iq): 5uA
Output Configuration: Positive
Output Current: 300mA
Operating Voltage: 8V
Output Type: Fixed
Features: Short Circuit Protection;Over Current Protection

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 50 (multiples of 50)
Unit weight: 0.035 g

Overview

XC6206 series are a highly precise, lower consumption, 3 terminal, positive voltage regulators manufactured using CMOS and laser trimming technologies. The series provides large currents with a significantly small dropout voltage. The XC6206 consists of a current limiter circuit, a driver transistor, a precision reference voltage and an error correction circuit. The series is compatible with low ESR ceramic capacitors. The current limiter’s foldback circuit operates as a short circuit protection as well as the output current limiter for the output pin. Output voltages are internally by laser trimming technologies. It is selectable in 0.1V increments within a range of 3.0V to 3.6V. XC6206 series are available in SOT - 23 package.
