TDSEMIC

XC6206P212MR

Linear Voltage Regulator IC Positive Fixed 1 Output 200mA SOT-23-3

SOT-23-3ROHS CompliantActive

IC REG LINEAR 2.1V 200mA SOT-23-3

Manufacturer: TDSEMIC
Manufacturer part #: XC6206P212MR
Store part #: C22466431
Package / case: SOT-23-3
Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

14,040 in stock

#C22466431

Stock & price checked 7 days ago

Quantity	Unit price	Pack price
20+	₹3.41	₹68.20
200+	₹2.66	₹532.00
600+	₹2.25	₹1,350.00
3,000+	₹2.00	₹6,000.00
9,000+	₹1.79	₹16,110.00
21,000+	₹1.67	₹35,070.00

Quantity (min 20, multiples of 20)

20 × ₹3.41

₹68.20

excl. GST

₹80.48 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

XC6206P212MR

₹68.20 for 20 + GST

Specifications

Output Voltage: 2.1V
Number of Outputs: 1
Operating Temperature: -40℃~+85℃@(Ta)
Supply Current (Iq): 6.5uA
Output Configuration: Positive
Output Current: 200mA
Operating Voltage: 6.5V
Features: Over Current Protection;Short Circuit Protection
Output Type: Fixed

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 20 (multiples of 20)
Unit weight: 0.035 g

Overview

The XC6206 series are high ripple rejection, low quiescent current, low dropout CMOS linear voltage regulators with overcurrent and short-circuit protection. These devices feature very low quiescent current (Typ. = 6.5μA), capable of delivering 200mA output current with minimal input-to-output voltage differential while maintaining good regulation. Due to the low dropout voltage and low quiescent current, these devices are particularly well-suited for battery-powered applications requiring extended battery life, such as computers, consumer electronics, and industrial equipment.
