XINGLIGHTDatasheet (PDF)
XL-1608SURC-06FJ
Red LED Indication - Discrete 1.8V~2.3V 0603
0603ROHS CompliantActive
LED RED WATER CLEAR 0603 SMD
- Manufacturer
- XINGLIGHT
- Manufacturer part #
- XL-1608SURC-06FJ
- Store part #
- C7371900
- Package / case
- 0603
- Category
- LED Indication - Discrete
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,70,950 in stock
#C7371900
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹2.69 | ₹134.50 |
| 500+ | ₹2.08 | ₹1,040.00 |
| 1,500+ | ₹1.75 | ₹2,625.00 |
| 4,000+ | ₹1.57 | ₹6,280.00 |
| 24,000+ | ₹1.40 | ₹33,600.00 |
| 48,000+ | ₹1.31 | ₹62,880.00 |
50 × ₹2.69
₹134.50
excl. GST
₹158.71 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
XL-1608SURC-06FJ
₹134.50 for 50 + GST
Specifications
- Installation method
- Top-mount
- Peak Wavelength
- 625nm
- Lens Color
- Water Clear
- Viewing Angle
- 120°
- Luminous Intensity
- 600mcd
- Forward Current
- 20mA
- Illumination Color
- Red
- Lamp Holder Type
- 1.6mm x 0.8mm square LED
- Voltage - Forward(Vf)
- 1.8V~2.3V
- Operating Temperature
- -40℃~+85℃
- Wavelength
- 618nm~630nm
- Diode Configuration
- Discrete Diode
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.02 g
Overview
Applications
- Medical devices: endoscopes, pulse oximeters
- Automotive electronics: backlit button lights, indicator lights
- Industrial products: electronic dashboards, industrial equipment
- Smart home: white goods, seven-segment LED displays
- Communication products: mobile phone button lights, routers, set-top boxes
Key features
- Dimensions (L/W/H): 1.6×0.8×0.6mm
- Emission color/lens: Red/clear lens
- RoHS-compliant, halogen-free process
- Moisture Sensitivity Level (MSL): Level 3
- EIA standard packaging
- Compatible with SMT automated assembly
- Low power consumption, wide viewing angle
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | XL-1608SURC-06#C965799XINGLIGHT · 0603 | XINGLIGHT | 0603 | 80,07,700 | ₹0.4631 · 80,07,700 in stock | View |
 | XL-1608SURC-04#C965798XINGLIGHT · 0603 | XINGLIGHT | 0603 | 3,12,500 | ₹0.7541 · 3,12,500 in stock | View |
 | XL-TD1608SURC#C965849XINGLIGHT · 0603 | XINGLIGHT | 0603 | 8,680 | ₹4.59 · 8,680 in stock | View |
 | XL-1608SRRC#C55338547XINGLIGHT · 0603 | XINGLIGHT | 0603 | 3,100 | ₹2.35 · 3,100 in stock | View |
 | XL-1608VRC-06#C7371906XINGLIGHT · 0603 | XINGLIGHT | 0603 | 65,650 | ₹1.55 · 65,650 in stock | View |
