Low offset high-side current monitor
- Manufacturer
- DIODES
- Manufacturer part #
- ZXCT1021E5TA
- Store part #
- C780912
- Package / case
- SOT-23-5
- Category
- Current Regulation/Management
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,994 in stock
#C780912
Stock & price checked 34 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹135.08 | ₹135.08 |
| 10+ | ₹117.52 | ₹1,175.20 |
| 30+ | ₹108.63 | ₹3,258.90 |
| 100+ | ₹99.95 | ₹9,995.00 |
| 500+ | ₹94.54 | ₹47,270.00 |
| 1,000+ | ₹91.94 | ₹91,940.00 |
1 × ₹135.08
₹135.08
excl. GST
₹159.39 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
ZXCT1021E5TA
₹135.08 for 1 + GST
Specifications
- Features
- High-side detection
- Vcm - Common Mode Voltage
- 2.5V~20V
- Bandwidth
- 300kHz
- Input Voltage (Vin)
- 2.5V~20V
- Operating Temperature
- -40℃~+85℃
- Gain
- 10V/V
- Quiescent Current
- 25uA
- Ib - Input Bias Current
- 100nA
- Number of Channels
- 1
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.13 g
Overview
The ZXCT1021 is a precision high-side current sense monitor. Using this type of device eliminates the need to disrupt the ground plane when sensing a load current. The ZXCT1021 provides a fixed gain of 10 for applications where minimal sense voltage is required. The very low offset voltage enables a typical accuracy of 3% for sense voltages of only 10mV, giving better tolerances for small sense resistors necessary at higher currents. The wide input voltage range of 20V down to as low as 2.5V make it suitable for a range of applications. With a minimum operating current of just 25μA, combined with its SOT23 - 5 package make it suitable for portable battery equipment too.
Applications
- Battery chargers
- Smart battery packs
- DC motor control
- Over current monitor
- Power management
- Level translating
- Programmable current source
Key features
- Accurate high-side current sensing
- Output voltage scaling
- 2.5V - 20V supply range
- 25μA quiescent current
- 1% typical accuracy
- SOT23-5 package
