MDD(Microdiode Semiconductor)Datasheet (PDF)
74AHC1G04GW
10uA 2V~5.5V 1 3.1ns@5V,15pF SOT-353 Gates and Inverters
SOT-353RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74AHC1G04GW
- Store part #
- C53954315
- Package / case
- SOT-353
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,580 in stock
#C53954315
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.26 | ₹92.60 |
| 100+ | ₹7.29 | ₹729.00 |
| 300+ | ₹6.31 | ₹1,893.00 |
| 3,000+ | ₹5.58 | ₹16,740.00 |
| 6,000+ | ₹4.99 | ₹29,940.00 |
| 9,000+ | ₹4.70 | ₹42,300.00 |
10 × ₹9.26
₹92.60
excl. GST
₹109.27 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AHC1G04GW
₹92.60 for 10 + GST
Specifications
- Input Logic Level - High
- 1.5V;2.1V;3.85V
- Operating Temperature
- -40℃~+125℃
- Input Logic Level - Low
- 500mV;900mV;1.65V
- Logic Family
- 74AHC
- Output Logic Level - High
- 1.9V;2.9V;4.4V;2.48V;3.8V
- Quiescent Current(Iq)
- 10uA
- Voltage - Supply
- 2V~5.5V
- Number of Channels
- 1
- Propagation Delay
- 3.1ns@5V,15pF
- Output Logic Level - Low
- 100mV;440mV
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.073 g
Overview
The 74AHC1G04 and 74AHCT1G04 are single inverters. The inputs are overvoltage tolerant, allowing these devices to be used as level translators in mixed-voltage environments. AHC devices feature CMOS input switching levels with a supply voltage range of 2V to 5.5V. AHCT devices feature TTL input switching levels with a supply voltage range of 4.5V to 5.5V.
Key features
- Wide supply voltage range: 2.0V to 5.5V
- Input overvoltage tolerance up to 5.5V
- High noise immunity
- CMOS low power consumption
- Latch-up performance exceeds 200mA
- Symmetrical output impedance
- Balanced propagation delay
- Input levels: CMOS for 74AHC1G04; TTL for 74AHCT1G04
- ESD protection: HBM (ANSI/ESDA/JEDEC JS-001 Class 3A) exceeds 7000V; CDM (ANSI/ESDA/JEDEC JS-002 Class C3) exceeds 2000V
- Multiple package options
