MDD(Microdiode Semiconductor)Datasheet (PDF)
74AHC1G32GV
StandardCMOS 2V~5.5V 6.5ns@5.5V,15pF 10nA SOT-23-5 Gates and Inverters
SOT-23-5RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74AHC1G32GV
- Store part #
- C52953347
- Package / case
- SOT-23-5
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,380 in stock
#C52953347
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.59 | ₹95.90 |
| 100+ | ₹7.55 | ₹755.00 |
| 300+ | ₹6.55 | ₹1,965.00 |
| 3,000+ | ₹5.78 | ₹17,340.00 |
| 6,000+ | ₹5.17 | ₹31,020.00 |
| 9,000+ | ₹4.87 | ₹43,830.00 |
10 × ₹9.59
₹95.90
excl. GST
₹113.16 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AHC1G32GV
₹95.90 for 10 + GST
Specifications
- Input Type
- StandardCMOS
- Logic Family
- 74AHC
- Voltage - Supply
- 2V~5.5V
- Propagation Delay
- 6.5ns@5.5V,15pF
- Output Logic Level - Low
- 100mV;440mV
- Input Logic Level - High
- 1.5V;2.1V;3.85V
- Input Logic Level - Low
- 500mV;900mV;1.65V
- Operating Temperature
- -40℃~+125℃
- Features
- Overvoltage-tolerant input
- Output Logic Level - High
- 1.9V;2.9V;4.4V
- Quiescent Current(Iq)
- 10nA
- Number of Channels
- 1;2
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.083 g
Overview
74AHC1G32 and 74AHCT1G32 are single 2-input OR gates. The inputs are 5 V tolerant, enabling the device to be used as a level translator in mixed-voltage environments.
Key features
- Wide supply voltage range: 2.0V to 5.5V
- Input overvoltage tolerance up to 5.5V
- High noise immunity
- CMOS low power consumption
- Latch-up performance exceeds 200 mA
- Symmetrical output impedance
- Balanced propagation delay
- Input levels: CMOS for 74AHC1G32; TTL for 74AHCT1G32
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3A exceeds 7000 V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
- Multiple package options
