MDD(Microdiode Semiconductor)

74HC04D

2V~6V 15ns@6V,15pF 40uA 6 SOP-14L Gates and Inverters

SOP-14LRoHSActive

Manufacturer: MDD(Microdiode Semiconductor)
Manufacturer part #: 74HC04D
Store part #: C52140401
Package / case: SOP-14L
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,916 in stock

#C52140401

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹18.57	₹18.57
10+	₹14.65	₹146.50
30+	₹12.67	₹380.10
100+	₹11.21	₹1,121.00
500+	₹10.03	₹5,015.00
1,000+	₹9.43	₹9,430.00

Quantity (min 1)

1 × ₹18.57

₹18.57

excl. GST

₹21.91 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

74HC04D

₹18.57 for 1 + GST

Specifications

Logic Family: 74HC
Voltage - Supply: 2V~6V
Output Logic Level - Low: 100mV;330mV
Propagation Delay: 15ns@6V,15pF
Input Logic Level - Low: 500mV;1.35V;1.8V
Input Logic Level - High: 1.5V;3.15V;4.2V
Operating Temperature: -40℃~+125℃
Output Logic Level - High: 1.9V;4.4V;5.9V
Quiescent Current(Iq): 40uA
Number of Channels: 6

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.406 g

Overview

The 74HC04 and 74HCT04 are hex inverters. The inputs include clamping diodes, which allow interfacing with input voltages exceeding VCC by using current-limiting resistors.

Key features

Wide supply voltage range: 2.0V to 6.0V
High noise immunity
CMOS low power consumption
Latch-up performance exceeds 250 mA
JEDEC compliant: JESD8C (2.7V to 3.6V) and JESD7A (2.0V to 6.0V)
Input levels: CMOS for 74HC04; TTL for 74HCT04
ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 2 exceeds 3500V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000V
Multiple package options
