SlkorDatasheet (PDF)
74HC08D
AND Gate IC 4 Channel SOP-14
SOP-14ROHS3 CompliantActive
4-channel 2-input AND gate
- Manufacturer
- Slkor
- Manufacturer part #
- 74HC08D
- Store part #
- C5355493
- Package / case
- SOP-14
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6,225 in stock
#C5355493
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹20.68 | ₹103.40 |
| 50+ | ₹16.55 | ₹827.50 |
| 150+ | ₹14.49 | ₹2,173.50 |
| 500+ | ₹12.94 | ₹6,470.00 |
| 2,500+ | ₹11.71 | ₹29,275.00 |
| 4,000+ | ₹11.09 | ₹44,360.00 |
5 × ₹20.68
₹103.40
excl. GST
₹122.01 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
74HC08D
₹103.40 for 5 + GST
Specifications
- Input Type
- TTL-compatible CMOS
- Logic Family
- 74HC
- Voltage - Supply
- 2V~6V
- Propagation Delay
- 15ns@6V,50pF
- Output Logic Level - Low
- 260mV
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - High
- 1.5V;3.15V;4.2V
- Input Logic Level - Low
- 500mV;1.35V;1.8V
- Output Logic Level - High
- 1.9V;4.4V;5.9V
- Quiescent Current(Iq)
- 2uA
- Current - Output High(IOH)
- 5.2mA
- Number of Channels
- 4;2
- Current - Output Low(IOL)
- 5.2mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.44 g
Overview
74HC08D is a high-speed CMOS circuit, pin-compatible with the Low-power Schottky TTL (LSTTL) family. The 74HC08D complies with JEDEC standard no. 7A. The 74HC08D implements a 2-input AND gate function.
Key features
- Compatible with JEDEC standard no.8-1A
- ESD protection
- HBM EIA/JESD22-A114-A exceeds 2000V
- MM EIA/JESD22-A115-A exceeds 200V
- Temperature range -40°C ~ +85°C
