6-channel Schmitt inverter

Manufacturer: TDSEMIC
Manufacturer part #: 74HC14-TD
Store part #: C42421774
Package / case: SOP-14
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

5,090 in stock

#C42421774

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹10.49	₹52.45
50+	₹9.21	₹460.50
150+	₹8.57	₹1,285.50
500+	₹8.08	₹4,040.00
2,500+	₹7.71	₹19,275.00
5,000+	₹7.51	₹37,550.00

Quantity (min 5, multiples of 5)

5 × ₹10.49

₹52.45

excl. GST

₹61.89 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

74HC14-TD

₹52.45 for 5 + GST

Specifications

Logic Family: 74HC
Input Type: Schmitt trigger
Voltage - Supply: 2V~6V
Output Logic Level - Low: 100mV;260mV
Propagation Delay: 21ns@6V,50pF
Features: Noise suppression function
Operating Temperature: -40℃~+85℃
Output Logic Level - High: 1.9V;4.4V;5.9V;3.98V;5.48V
Quiescent Current(Iq): 2uA
Number of Channels: 6
Current - Output Low(IOL): 5.2mA

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.179 g

Overview
