74HC86NS14ARDQ

XOR Gate IC 4 Channel SOP-14

SOP-14RoHSActive

Quadruple 2-input XOR gates

Manufacturer: GR
Manufacturer part #: 74HC86NS14ARDQ
Store part #: C47089303
Package / case: SOP-14
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,360 in stock

#C47089303

Stock & price checked 33 h ago

Quantity	Unit price	Pack price
5+	₹12.34	₹61.70
50+	₹9.75	₹487.50
150+	₹8.47	₹1,270.50
500+	₹7.50	₹3,750.00
2,500+	₹6.72	₹16,800.00
4,000+	₹6.34	₹25,360.00

Quantity (min 5, multiples of 5)

5 × ₹12.34

₹61.70

excl. GST

₹72.81 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

74HC86NS14ARDQ

₹61.70 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Input Logic Level - High: 1.5V;3.15V;4.2V
Logic Family: 74HC
Input Logic Level - Low: 500mV;1.35V;1.8V
Operating Temperature: 0℃~+70℃
Output Logic Level - High: 1.9V;4.4V;5.9V;4V;5.5V
Quiescent Current(Iq): 10uA
Voltage - Supply: 2V~6V
Current - Output High(IOH): 5.2mA
Number of Channels: 4;2
Output Logic Level - Low: 100mV;260mV
Current - Output Low(IOL): 5.2mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.356 g

Overview

This device contains four independent dual-input XOR gates. Each gate performs the Boolean function Y = A ⊕ B in positive logic.

Key features

Buffered inputs
Wide supply voltage range: VCC = 2V ~ 6V
Wide operating temperature range: 0℃ ~ 70℃
Fan-out capability supporting up to 10 LSTTL loads
Significantly reduced power consumption compared to LSTTL logic ICs
