74LV1T126GV-TP
SOT-23-5 Translators, Level Shifters
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- 74LV1T126GV-TP
- Store part #
- C52098012
- Package / case
- SOT-23-5
- Category
- Translators, Level Shifters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,940 in stock
#C52098012
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹10.62 | ₹53.10 |
| 50+ | ₹8.35 | ₹417.50 |
| 150+ | ₹7.22 | ₹1,083.00 |
| 500+ | ₹6.36 | ₹3,180.00 |
| 3,000+ | ₹5.69 | ₹17,070.00 |
| 6,000+ | ₹5.34 | ₹32,040.00 |
5 × ₹10.62
₹53.10
excl. GST
₹62.66 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LV1T126GV-TP
₹53.10 for 5 + GST
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.036 g
Overview
This device is a single-channel level-shifting buffer driver with tri-state output. The tri-state output is controlled by an output enable input; when the input is low, the output enters a high-impedance shutdown state. Output levels are referenced to the supply voltage, supporting 1.8V, 2.5V, 3.3V, and 5.0V CMOS logic levels. Its low-threshold inputs support 1.8V input logic at VCC = 3.3V, enabling level translation from 1.8V to 3.3V.
Applications
- AV receiver
- Embedded PC
- Solid-state drive
Key features
- Operating voltage range: 1.6V to 5.5V
- Low quiescent current: Icc = 10μA (maximum)
- Output drive capability: ±8mA (VCC = 5.0V)
- Power-off protection
- ESD protection exceeds JESD 22 standard
- Human Body Model: 2000V
- Machine Model: 200V
- Charged Device Model: 1000V
