Nexperia

74LVC04ABQ,115

Schmitt trigger 1.2V~3.6V 4.5ns@3.3V,50pF 40uA 6 DHVQFN-14-EP(2.5x3) Gates and Inverters RoHS

DHVQFN-14-EP(2.5x3)ROHS3 CompliantActive

Hex inverter

Manufacturer: Nexperia
Manufacturer part #: 74LVC04ABQ,115
Store part #: C548045
Package / case: DHVQFN-14-EP(2.5x3)
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,981 in stock

#C548045

Stock & price checked 43 h ago

Quantity	Unit price	Pack price
1+	₹118.55	₹118.55
10+	₹95.07	₹950.70
30+	₹83.32	₹2,499.60
100+	₹71.57	₹7,157.00
500+	₹64.62	₹32,310.00
1,000+	₹60.91	₹60,910.00

Quantity (min 1)

1 × ₹118.55

₹118.55

excl. GST

₹139.89 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

74LVC04ABQ,115

₹118.55 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

output type: Push-pull
Logic Family: 74LVC
Input Type: Schmitt trigger
Voltage - Supply: 1.2V~3.6V
Output Logic Level - Low: 800mV
Propagation Delay: 4.5ns@3.3V,50pF
Features: Noise suppression function
Operating Temperature: -40℃~+125℃
Input Logic Level - Low: 120mV~800mV
Input Logic Level - High: 1.08V~2V
Output Logic Level - High: 2V
Quiescent Current(Iq): 40uA
Current - Output High(IOH): 24mA
Number of Channels: 6
Current - Output Low(IOL): 24mA

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.051 g

Overview

The 74LVC04A is a hex inverter. Inputs can be driven from either 3.3 V or 5 V devices. This feature allows the use of these devices as translators in mixed 3.3 V and 5 V environments. Schmitt-trigger action at all inputs makes the circuit tolerant of slower input rise and fall times.

Key features

Overvoltage tolerant inputs to 5.5 V
Wide supply voltage range from 1.2 V to 3.6 V
CMOS low power consumption
Direct interface with TTL levels
Complies with JEDEC standard: JESD8-7A (1.65 V to 1.95 V); JESD8-5A (2.3 V to 2.7 V); JESD8-C/JESD36 (2.7 V to 3.6 V)
ESD protection: HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V; CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
Specified from -40 °C to +85 °C and -40 °C to +125 °C
