MDD(Microdiode Semiconductor)Datasheet (PDF)
74LVC08APW
Schmitt trigger 1.65V~5.5V 3.3ns@4.5V,15pF 10nA TSSOP-14L Gates and Inverters
TSSOP-14LRoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74LVC08APW
- Store part #
- C54411084
- Package / case
- TSSOP-14L
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,610 in stock
#C54411084
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹20.23 | ₹101.15 |
| 50+ | ₹15.86 | ₹793.00 |
| 150+ | ₹13.98 | ₹2,097.00 |
| 500+ | ₹11.64 | ₹5,820.00 |
| 2,500+ | ₹10.61 | ₹26,525.00 |
| 5,000+ | ₹9.98 | ₹49,900.00 |
5 × ₹20.23
₹101.15
excl. GST
₹119.36 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
74LVC08APW
₹101.15 for 5 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Family
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Propagation Delay
- 3.3ns@4.5V,15pF
- Output Logic Level - Low
- 450mV;300mV;400mV;550mV
- Input Logic Level - Low
- 700mV;800mV
- Operating Temperature
- -40℃~+125℃
- Input Logic Level - High
- 1.7V;2V
- Output Logic Level - High
- 1.2V;1.9V;2.2V;2.4V;3.8V
- Quiescent Current(Iq)
- 10nA
- Number of Channels
- 4;2
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.265 g
Overview
The 74LVC08A is a quad 2-input AND gate. Inputs can be driven by 3.3V or 5V devices. This feature allows use of these devices as translators in mixed 3.3V and 5V applications. Schmitt-trigger action on all inputs enables the circuit to tolerate slower input rise and fall times. The device is fully specified for partial power-down applications using IOFF. The IOFF circuit disables the outputs, preventing potentially damaging backflow current through the device when it is powered down.
Key features
- Wide supply voltage range: 1.2V to 5.5V
- Input overvoltage tolerance up to 5.5V
- CMOS low power consumption
- Latch-up performance exceeds 250mA
- Direct TTL-level interface
- IOFF circuit for partial power-down mode operation
- JEDEC standard compliant:
- JESD8-7 (1.65V to 1.95V)
- JESD8-5 (2.3V to 2.7V)
- JESD8C (2.7V to 3.6V)
- JESD36 (4.5V to 5.5V)
- ESD protection:
- HBM ANSI/ESDA/JEDEC JS-001 Class 3A exceeds 6000V
- CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000V
- Multiple package options
