74LVC1G08GW
₹7.62 for 1 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Family
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Propagation Delay
- 3.8ns@4.5V,50pF
- Output Logic Level - Low
- 550mV~800mV
- Features
- Local shutdown mode;Overvoltage-tolerant input
- Operating Temperature
- -40℃~+125℃
- Output Logic Level - High
- 3.4V~3.8V
- Quiescent Current(Iq)
- 4uA
- Number of Channels
- 1;2
- Current - Output High(IOH)
- 32mA
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1 g
Overview
The 74LVC1G08 is a single 2-input AND gate. Its inputs can be driven by 3.3V or 5V devices. This feature allows the device to be used as a level translator in mixed 3.3V and 5V applications. Schmitt-trigger action on all inputs makes the circuit tolerant of slower input rise and fall times. The device is fully specified for partial-power-down applications using I_OFF. The I_OFF circuit disables the outputs, preventing damaging backflow current when the device is powered down.
Key features
- Wide supply voltage range: 1.65V to 5.5V
- High noise immunity
- ±24 mA output drive capability (V_CC = 3.0V)
- CMOS low power consumption
- Direct TTL-level interface compatible
- Input overvoltage tolerance up to 5.5V
- I_OFF circuitry supports partial power-down mode operation
- Latch-up performance exceeds 100 mA
- JEDEC standard compliant
- ESD protection
- Multiple package options
