MDD(Microdiode Semiconductor)Datasheet (PDF)
74LVC2G06GW
Schmitt trigger 1.65V~5.5V 2ns@5V,50pF 4uA 2 SOT-363 Gates and Inverters
SOT-363RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74LVC2G06GW
- Store part #
- C52140490
- Package / case
- SOT-363
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,891 in stock
#C52140490
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹21.00 | ₹21.00 |
| 10+ | ₹16.46 | ₹164.60 |
| 30+ | ₹14.51 | ₹435.30 |
| 100+ | ₹12.08 | ₹1,208.00 |
| 500+ | ₹11.01 | ₹5,505.00 |
| 1,000+ | ₹10.36 | ₹10,360.00 |
1 × ₹21.00
₹21.00
excl. GST
₹24.78 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LVC2G06GW
₹21.00 for 1 + GST
Specifications
- output type
- Open-drain
- Logic Family
- 74LVC
- Input Type
- Schmitt trigger
- Voltage - Supply
- 1.65V~5.5V
- Propagation Delay
- 2ns@5V,50pF
- Output Logic Level - Low
- 800mV
- Features
- Power shutdown protection;Noise suppression function
- Input Logic Level - Low
- 700mV~800mV
- Operating Temperature
- -40℃~+125℃
- Input Logic Level - High
- 1.7V~2V
- Quiescent Current(Iq)
- 4uA
- Number of Channels
- 2
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.073 g
Overview
The 74LVC2G06 is a dual inverter with open-drain outputs. Its inputs can be driven by 3.3V or 5V devices. This feature allows the device to be used as a level translator in mixed 3.3V and 5V environments. Schmitt-trigger action on all inputs makes the circuit tolerant of slower input rise and fall times. The device is fully suited for partial power-down applications using I_OFF. The I_OFF circuit disables the outputs, preventing potentially destructive backflow current through the device when it is powered down.
Key features
- Wide supply voltage range: 1.65V ~ 5.5V
- Input overvoltage tolerance up to 5.5V
- High noise immunity
- CMOS low power consumption
- I_OFF circuit for partial power-down mode operation
- 24mA output drive capability (V_CC = 3.0V)
- Latch-up performance exceeds 100mA
- Direct TTL-level interface compatible
- JEDEC standard compliant
- ESD protection
- Multiple package options
- Inverter with open-drain output
