JSMSEMIDatasheet (PDF)
74LVC2G14GV-JSM
Schmitt trigger 1.65V~5.5V 4uA 2 SOT-23-6 Gates and Inverters RoHS
SOT-23-6ROHS CompliantActive
- Manufacturer
- JSMSEMI
- Manufacturer part #
- 74LVC2G14GV-JSM
- Store part #
- C53436297
- Package / case
- SOT-23-6
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
8,230 in stock
#C53436297
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹11.07 | ₹55.35 |
| 50+ | ₹8.81 | ₹440.50 |
| 150+ | ₹7.69 | ₹1,153.50 |
| 500+ | ₹6.84 | ₹3,420.00 |
| 3,000+ | ₹6.15 | ₹18,450.00 |
| 6,000+ | ₹5.82 | ₹34,920.00 |
5 × ₹11.07
₹55.35
excl. GST
₹65.31 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LVC2G14GV-JSM
₹55.35 for 5 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Family
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Output Logic Level - Low
- 100mV;700mV;450mV;600mV;800mV
- Operating Temperature
- -40℃~+125℃
- Output Logic Level - High
- 950mV;1.7V;1.9V;2V;3.4V
- Quiescent Current(Iq)
- 4uA
- Current - Output High(IOH)
- 32mA
- Number of Channels
- 2
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.043 g
Overview
The 74LVC2G14 provides two inverting buffers with Schmitt-trigger inputs. It converts slowly changing input signals into clean, bounce-free output signals. The inputs can be driven by 3.3V or 5V devices. This feature allows the device to be used in mixed 3.3V and 5V environments. The Schmitt-trigger action at the inputs enables the circuit to tolerate slow input rise and fall times.
Key features
- Wide supply voltage range: 1.65V to 5.5V
- 5V-tolerant inputs for 5V logic interfacing
- ±24mA output drive (VCC = 3.0V)
- CMOS low power consumption
- Direct TTL-level interfacing
- Unlimited rise and fall times
- Operating temperature range: -40°C to +125°C
- Package: SOT-23-6/SOT-363
