TL431Shunt Voltage Reference IC Adjustable 2.5V~36V ±1% 150mA SOT-23
From
₹8.07
4,89,020 in stock
TECH PUBLICDatasheet (PDF)
AN431AN-TP
Shunt Voltage Reference IC Adjustable 2.5V~36V ±0.5% 100mA SOT-23
SOT-23RoHSActive
Precision adjustable reference source
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- AN431AN-TP
- Store part #
- C49190778
- Package / case
- SOT-23
- Category
- Voltage Reference
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,840 in stock
#C49190778
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.07 | ₹80.70 |
| 100+ | ₹6.42 | ₹642.00 |
| 300+ | ₹5.58 | ₹1,674.00 |
| 3,000+ | ₹4.96 | ₹14,880.00 |
| 6,000+ | ₹4.47 | ₹26,820.00 |
| 9,000+ | ₹4.22 | ₹37,980.00 |
10 × ₹8.07
₹80.70
excl. GST
₹95.23 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
AN431AN-TP
₹80.70 for 10 + GST
Specifications
- Output Voltage
- 2.5V~36V
- Tolerance
- ±0.5%
- Voltage - Supply
- 2.5V~36V
- Minimum Cathode Current for Regulation
- 1mA
- Reference Type
- Parallel
- Output Current
- 100mA
- Operating Temperature
- -40℃~+125℃
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.032 g
Overview
This device is a three-terminal adjustable shunt voltage regulator with an output voltage settable to any value between Vref (approximately 2.5V) and 36V using two external resistors. These devices feature an output impedance of 0.15 Ω (typical). The active output circuitry provides a very sharp turn-on characteristic, making them an excellent replacement for Zener diodes in numerous applications. Typical applications include on-board voltage regulation, adjustable power supplies, and power-on/power-off protection.
Applications
- Adjustable voltage and current reference
- Zener diode replacement
- Voltage monitoring
- Comparator with integrated reference
- Secondary-side voltage regulation in flyback switching power supplies
Key features
- Adjustable output voltage range: 2.5V~36V
- Low dynamic output resistance: 0.15 Ω (typical)
- Low temperature drift: 5 mV (typical)
- Low output noise
- High capacitive load stability
- Current capacity range: 1~100 mA
- Accuracy: 0.5%
- Package: SOT23
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | AS431ANTR-TP#C47117517TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 2,580 | ₹5.69 · 2,580 in stock | View |
 | AZ431BN-TP#C47117518TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 2,460 | ₹5.66 · 2,460 in stock | View |
 | TP431R250S3#C47117583TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 900 | ₹7.03 · 900 in stock | View |
 | TPNCP431AISNT1G#C47117630TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 855 | ₹9.91 · 855 in stock | View |
 | TPNCP431AVSNT1G#C47117631TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 2,605 | ₹10.03 · 2,605 in stock | View |
