ASDsemiDatasheet (PDF)
ASL485S-R
5V Transceiver 10Mbps 128 SOP-8 Drivers, Receivers, Transceivers RoHS
SOP-8ROHS CompliantActive
ASL485S RS485 Transceivers
- Manufacturer
- ASDsemi
- Manufacturer part #
- ASL485S-R
- Store part #
- C7528170
- Package / case
- SOP-8
- Category
- Drivers, Receivers, Transceivers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,685 in stock
#C7528170
Stock & price checked 30 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹20.85 | ₹104.25 |
| 50+ | ₹18.20 | ₹910.00 |
| 150+ | ₹17.08 | ₹2,562.00 |
| 500+ | ₹15.66 | ₹7,830.00 |
| 2,500+ | ₹15.03 | ₹37,575.00 |
| 4,000+ | ₹14.66 | ₹58,640.00 |
5 × ₹20.85
₹104.25
excl. GST
₹123.02 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
ASL485S-R
₹104.25 for 5 + GST
Specifications
- Voltage - Supply
- 5V
- Type
- Transceiver
- Data Rate
- 10Mbps
- Number of Nodes
- 128
- Operating Temperature
- -40℃~+85℃
- ESD Protect
- ±15kV
- Number of Drivers
- 1
- Features
- Tx/Rx enable;Enable shutdown;Low-power mode
- Number of Receivers
- 1
- Quiescent Supply Current
- 900uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.143 g
Overview
The ASL485S is high-speed transceivers for RS-485 communication, which contain one driver and one receiver. The ASL485S feature fail-safe circuitry, which guarantees a logic-high receiver output when the receiver inputs are open or shorted. This means that the receiver output will be a logic high if all transmitters on a terminated bus are disabled (high impedance). The ASL485S driver slew rates are not limited, making transmit speeds up to 10Mbps possible. And this device has a 1/8-unit-load receiver input impedance that allows up to 128 transceivers on the bus.
Applications
- RS-485 Communications Level Translators
- Security Equipment
- Industrial Control Equipment
- Watt-hour meter
Key features
- Fail-safe circuitry
- Low power consumption
- Up to 128 transceivers can be attached to the bus
- Maximum transmission rate: 10Mbps
- ESD: ≥±15kV SOP8 Package
