ROHMDatasheet (PDF)
BD00KA5WF-E2
1V~4V Positive Adjustable SOP-8 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOP-8ROHS CompliantActive
500mA Variable/Fixed LDO Regulators
- Manufacturer
- ROHM
- Manufacturer part #
- BD00KA5WF-E2
- Store part #
- C161948
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,511 in stock
#C161948
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹62.88 | ₹62.88 |
| 10+ | ₹52.22 | ₹522.20 |
| 30+ | ₹47.71 | ₹1,431.30 |
| 100+ | ₹42.10 | ₹4,210.00 |
| 500+ | ₹39.57 | ₹19,785.00 |
| 1,000+ | ₹37.95 | ₹37,950.00 |
1 × ₹62.88
₹62.88
excl. GST
₹74.20 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
BD00KA5WF-E2
₹62.88 for 1 + GST
Specifications
- Output Voltage
- 1V~4V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+105℃
- Supply Current (Iq)
- 350uA
- Output Configuration
- Positive
- Operating Voltage
- 5.5V
- Output Current
- 500mA
- Features
- Enable control;Over Current Protection;Thermal shutdown
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.054 g
Overview
The BDxxKA5 series are low-saturation regulators that are available for output currents up to 500mA. The output voltage precision is ± 1%. These LDO regulators are offered in several output voltages and package lineups with or without ON/OFF switches (that set the circuit current to 0μA at shutdown). This series can be used for a broad spectrum of applications ranging from TVs and car audio systems to HDDs, PCs, and DVDs. There regulators have a built-in overcurrent protection circuit that prevents the destruction of the IC, due to output short circuits and a thermal shutdown circuit.
Applications
- Microcontrollers and all electronic devices that use logic circuit
Key features
- Output voltage precision: ±1%
- Low-saturation voltage with PMOS output: 0.12V Typ.(10 = 200mA)
- Built-in over-current protection circuit
- Built-in thermal shutdown circuit
- Shutdown switch (BDxxKA5WFP and BDxxKA5WF series)
- Ceramic capacitor compatible (recommended capacitance: 1μF or greater)
