BD800M5WHFP-CTR

1.2V~16V Positive Adjustable TO-263-6 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS

TO-263-6ROHS3 CompliantActive

Manufacturer: ROHM
Manufacturer part #: BD800M5WHFP-CTR
Store part #: C6130805
Package / case: TO-263-6
Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

48 in stock

#C6130805

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
1+	₹272.54	₹272.54
10+	₹265.45	₹2,654.50
30+	₹260.94	₹7,828.20
100+	₹256.42	₹25,642.00

Quantity (min 1)

1 × ₹272.54

₹272.54

excl. GST

₹321.60 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,000 per reel

BD800M5WHFP-CTR

₹272.54 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Voltage: 1.2V~16V
Number of Outputs: 1
Operating Temperature: -40℃~+150℃
Supply Current (Iq): 17uA
Output Configuration: Positive
Output Current: 500mA
Operating Voltage: 42V
Features: Enable control;Over Current Protection;Thermal shutdown;Output discharge
Output Type: Adjustable

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.571 g

Overview

The BD800M5Wxxx-C series are linear regulators designed for low current consumption, intended for power supply use in various automotive applications. These products support a maximum voltage of up to 45V, an output current of up to 500mA, and a current consumption as low as 17μA (typical). They regulate output with high accuracy: ±2% (BD800M5WFPJ-C, BD800M5WHFP-C) and ±2.6% (BD800M5WFP2-C). The output voltage is adjustable from 1.2V to 16V via an external resistor divider connected to the adjustment pin. These regulators are therefore well-suited for applications requiring direct battery connection with low current consumption. A logic "High" on the EN pin enables the device, while a logic "Low" input to the EN pin disables it. The device integrates overcurrent protection to guard against damage caused by short circuits or overload conditions. Thermal shutdown protection is also integrated to prevent damage due to overheating. In addition, low-ESR ceramic capacitors are suitable for phase compensation.
