BDJ2FC0WFP-E2
12V Positive Fixed TO-252-5 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-252-5ROHS3 CompliantActive
- Manufacturer
- ROHM
- Manufacturer part #
- BDJ2FC0WFP-E2
- Store part #
- C3749454
- Package / case
- TO-252-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
33 in stock
#C3749454
Stock & price checked 37 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹96.27 | ₹96.27 |
| 10+ | ₹93.89 | ₹938.90 |
| 30+ | ₹92.37 | ₹2,771.10 |
| 100+ | ₹90.64 | ₹9,064.00 |
1 × ₹96.27
₹96.27
excl. GST
₹113.60 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
BDJ2FC0WFP-E2
₹96.27 for 1 + GST
Specifications
- Output Voltage
- 12V
- Number of Outputs
- 1
- Operating Temperature
- -25℃~+85℃@(Ta)
- Supply Current (Iq)
- 500uA
- Output Configuration
- Positive
- Output Current
- 1A
- Operating Voltage
- 26.5V
- Features
- Enable control;Over Current Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.56 g
Overview
The BDxxFC0 series are low-saturation regulators. The series’ output voltages are Variable, 3.0V, 3.3V, 5.0V, 6.0V, 7.0V, 8.0V, 9.0V, 10.0V, 12.0V and 15.0V and packages are HTSOP-J8, TO252-3, and TO252-5. This series has a built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits and a thermal shutdown circuit that protects the IC from thermal damage due to overloading.
Key features
- Output Voltage: 1.0V to 15.0V
- Output Voltage Precision( Ta = 25℃ ): ±1%
- Supply Voltage (V0 ≥ 3.0V): V0 + 1.0V to 26.5V
- Supply Voltage (Vo < 3.0V): 4.0V to 26.5V
- Output Current: 1A
- Operating Temperature Range: -25℃ ≤ Ta ≤ +85℃
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| SI-3120KM#C7080220SANKEN · TO-252-5 | SANKEN | TO-252-5 | On request | ₹151.21 · 0 in stock | View | |
| R1501J120B-T1-JE#C3746076Nisshinbo Micro Devices Inc. · TO-252-5-P2 | Nisshinbo Micro Devices Inc. | TO-252-5-P2 | On request | ₹186.33 · 0 in stock | View | |
