CD4011ALQ/TR
TTL-compatible CMOS 3V~13V 1uA QFN-16(3x3) Gates and Inverters
QFN-16(3x3)RoHSActive
- Manufacturer
- HGSEMI
- Manufacturer part #
- CD4011ALQ/TR
- Store part #
- C50703795
- Package / case
- QFN-16(3x3)
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,715 in stock
#C50703795
Stock & price checked 41 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹11.09 | ₹55.45 |
| 50+ | ₹9.70 | ₹485.00 |
| 150+ | ₹9.00 | ₹1,350.00 |
| 500+ | ₹8.48 | ₹4,240.00 |
| 2,500+ | ₹8.07 | ₹20,175.00 |
| 5,000+ | ₹7.86 | ₹39,300.00 |
5 × ₹11.09
₹55.45
excl. GST
₹65.43 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
CD4011ALQ/TR
₹55.45 for 5 + GST
Specifications
- Input Type
- TTL-compatible CMOS
- Logic Family
- 4000 Series
- Voltage - Supply
- 3V~13V
- Output Logic Level - Low
- 50mV
- Propagation Delay
- 250ns@5V,50pF;100ns@10V,50pF;70ns@13V,50pF
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - Low
- 0V~1.5V;0V~3V;0V~3.5V
- Input Logic Level - High
- 3.5V~5V;7V~10V;10V~13V
- Output Logic Level - High
- 4.95V~5V;9.95V~10V;12.95V~13V
- Quiescent Current(Iq)
- 1uA
- Current - Output High(IOH)
- 8.8mA
- Number of Channels
- 4;2
- Current - Output Low(IOL)
- 8.8mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.135 g
Overview
The CD4011A consists of four 2-input NAND gates, fabricated using wide-voltage CMOS IC technology. It offers the advantages of low power consumption, high noise immunity, and flexible application. It features symmetrical source and sink current drive capability, compliant with the CD4000 series output driver standard. The device incorporates output buffering to provide very high gain, improving transfer characteristics and switching performance, while remaining insensitive to output impedance. To prevent electrostatic breakdown, all inputs are protected by diodes to VDD and VSS; unused inputs must be connected to VDD, VSS, or other inputs. The device is available in SOP-14, TSSOP-14, DIP-14, QSOP-16, and QFN-16 packages.
Applications
- NAND logic gate
- High-noise environment systems
- Pulse shaper
Key features
- Operating voltage range: 3~13V
- TTL compatible
- Symmetrical output characteristics
- Input/output ESD protection
