JSCJ

CJ74LVC1G57R6N

Schmitt trigger 1.65V~5.5V 5.1ns@4.5V,50pF 4uA SOT-363 Gates and Inverters

SOT-363RoHSActive

Manufacturer: JSCJ
Manufacturer part #: CJ74LVC1G57R6N
Store part #: C52145612
Package / case: SOT-363
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,000 in stock

#C52145612

Stock & price checked 34 h ago

Quantity	Unit price	Pack price
5+	₹13.53	₹67.65
50+	₹13.22	₹661.00
150+	₹13.01	₹1,951.50
500+	₹12.78	₹6,390.00

Quantity (min 5, multiples of 5)

5 × ₹13.53

₹67.65

excl. GST

₹79.83 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

CJ74LVC1G57R6N

₹67.65 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Input Type: Schmitt trigger
Logic Family: 74LVC
Voltage - Supply: 1.65V~5.5V
Propagation Delay: 5.1ns@4.5V,50pF
Output Logic Level - Low: 450mV;550mV;700mV;800mV
Features: Local shutdown mode
Operating Temperature: -40℃~+125℃
Output Logic Level - High: 1.2V;1.9V;2.3V;3.8V
Quiescent Current(Iq): 4uA
Current - Output High(IOH): 24mA
Number of Channels: 1;3
Current - Output Low(IOL): 24mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.185 g

Overview

The CJ74LVC1G57 is a configurable multifunction logic gate. Its output state is determined by eight modes of 3-bit input. Users can select AND, OR, NAND, NOR, XNOR, inverter, and buffer logic functions. All inputs can be connected to VCC or GND. Inputs can be driven by 3.3V or 5V devices, allowing the device to be used in mixed 3.3V and 5V environments. The device fully supports partial power-down applications using IOFF. The IOFF circuit disables the output during power-down, preventing harmful backflow current from flowing through the device. All inputs (A, B, and C) are Schmitt-trigger inputs, capable of converting slowly changing input signals into clean, bounce-free output signals.
