DRV8711DCPR
HTSSOP-38-EP-4.4mm Motor Drivers, Controllers RoHS
Stepper motor controller integrated circuit (IC)
- Manufacturer
- TI
- Manufacturer part #
- DRV8711DCPR
- Store part #
- C60013
- Package / case
- HTSSOP-38-EP-4.4mm
- Category
- Motor Drivers, Controllers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,334 in stock
#C60013
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹448.33 | ₹448.33 |
| 10+ | ₹380.24 | ₹3,802.40 |
| 30+ | ₹337.60 | ₹10,128.00 |
| 100+ | ₹285.19 | ₹28,519.00 |
| 500+ | ₹265.38 | ₹1,32,690.00 |
| 1,000+ | ₹256.90 | ₹2,56,900.00 |
1 × ₹448.33
₹448.33
excl. GST
₹529.03 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
DRV8711DCPR
₹448.33 for 1 + GST
Specifications
- Drive Type
- Bipolar Driver
- Number of H-bridges
- 2
- Features
- Motor step-out prevention function;Overcurrent Protection;Over temperature protection;Under-voltage lockout;Built-in charge pump;Dead-time / shoot-through protection
- Technology
- No
- Interface
- SPI;STEP/DIR
- Operating Temperature
- -40℃~+85℃
- Step Resolution
- 1;2;4;8;16;32;64;128;256
- Motor Drive Voltage(Vm)
- 8V~52V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 2 (1 year)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.135 g
Overview
The DRV8711 is a stepper motor controller that uses external N-channel MOSFETs to drive a bipolar stepper motor or two brushed DC motors. It integrates a microstepping indexer and can support stepping modes from full-step to 1/256-step. By using adaptive blanking time and various different current decay modes, including the automatic mixed decay mode, a very smooth motion system configuration can be achieved. The motor stall is reported by an optional back electromotive force (EMF) output. A simple step/direction or pulse-width modulation (PWM) interface can be easily connected to the controller circuit. An SPI serial interface is used to set the device operation. The output current (torque), stepping mode, decay mode, and stall detection function can all be programmed through the SPI serial interface. The internal shutdown function supports overcurrent protection, short-circuit protection, undervoltage lockout, and over-temperature protection. A FAULTn pin is used to indicate fault conditions, and each fault condition is reported by a dedicated bit through the SPI. The DRV8711 is available in a 38-pin heat-enhanced thin shrink small-outline package (HTSSOP) with a thermal pad (Environmentally friendly: RoHS compliant and lead/bromine free).
Applications
- Office automation equipment
- Factory automation
- Textile machinery
- Robotics
Key features
- PWM microstepping motor driver
- Integrated 1/256-step microstepping indexer
- Drives external N-channel MOSFETs
- Optional STEP/DIR pins
- Optional PWM control interface for DC motor control
- Overcurrent protection (OCP)
- Overtemperature shutdown (OTS)
- Undervoltage lockout (UVLO)
- Individual fault condition indicator bits
- Flexible decay modes including automatic mixed decay
- Stall detection with optional back-EMF (BEMF) output
- Highly configurable SPI serial interface
- Internal reference and torque DAC
- 8V to 52V operating supply voltage range
- Scalable output current
- Thermally enhanced SMT package
- 5V regulator capable of handling 10mA load
