EM74LVC00AD
Schmitt trigger 1.65V~5.5V 5.5ns@5.5V,15pF 40uA SOP-14L Gates and Inverters
SOP-14LRoHSActive
Quad 2-input NAND gate
- Manufacturer
- EnergyMath
- Manufacturer part #
- EM74LVC00AD
- Store part #
- C49188184
- Package / case
- SOP-14L
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,725 in stock
#C49188184
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹14.41 | ₹72.05 |
| 50+ | ₹11.32 | ₹566.00 |
| 150+ | ₹9.79 | ₹1,468.50 |
| 500+ | ₹8.64 | ₹4,320.00 |
| 3,000+ | ₹7.71 | ₹23,130.00 |
| 6,000+ | ₹7.25 | ₹43,500.00 |
5 × ₹14.41
₹72.05
excl. GST
₹85.02 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
EM74LVC00AD
₹72.05 for 5 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Family
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Propagation Delay
- 5.5ns@5.5V,15pF
- Output Logic Level - Low
- 650mV;450mV;600mV;800mV
- Features
- Local shutdown mode;Overvoltage-tolerant input
- Input Logic Level - Low
- 120mV;700mV;800mV
- Operating Temperature
- -40℃~+125℃
- Input Logic Level - High
- 1.08V;1.7V;2V
- Output Logic Level - High
- 1.05V;1.7V;2.05V;2.25V;3.5V
- Quiescent Current(Iq)
- 40uA
- Current - Output High(IOH)
- 32mA
- Number of Channels
- 4;2
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.276 g
Overview
The EM74LVC00A is a quad 2-input NAND gate. Its inputs can be driven by 3.3V or 5V devices. This feature allows the device to be used as a level translator in mixed 3.3V and 5V environments. All inputs incorporate Schmitt-trigger action, enabling the circuit to tolerate slow input rise and fall times. The device fully supports partial power-down applications using the IOFF circuit. The IOFF circuit disables the outputs when the device is powered down, preventing potentially damaging reverse current from flowing through the device.
Key features
- Wide supply voltage range: 1.2V to 5.5V
- Input overvoltage tolerance up to 5.5V
- CMOS low power consumption
- I<sub>OFF</sub> circuitry supports partial power-down mode operation
- Latch-up performance exceeds 250mA
- Direct interface with TTL levels
- JEDEC compliant: JESD8-7 (1.65V to 1.95V), JESD8-5 (2.3V to 2.7V), JESD8C (2.7V to 3.6V), JESD36 (4.5V to 5.5V)
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3A exceeds 6000V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000V
- Multiple package options
Alternatives
Similar parts — check the datasheet before substituting.
