EnergyMath

EM74LVC1G11GV

Schmitt trigger 1.65V~5.5V 3.8ns@5.5V,50pF 4uA SOT-23-6L Gates and Inverters

SOT-23-6LRoHSActive

Single 3-input AND gate

Manufacturer: EnergyMath
Manufacturer part #: EM74LVC1G11GV
Store part #: C49188139
Package / case: SOT-23-6L
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,980 in stock

#C49188139

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
10+	₹7.46	₹74.60
100+	₹5.90	₹590.00
300+	₹5.12	₹1,536.00
3,000+	₹4.52	₹13,560.00
6,000+	₹4.06	₹24,360.00
9,000+	₹3.82	₹34,380.00

Quantity (min 10, multiples of 10)

10 × ₹7.46

₹74.60

excl. GST

₹88.03 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

EM74LVC1G11GV

₹74.60 for 10 + GST

Specifications

Input Type: Schmitt trigger
Logic Family: 74LVC
Voltage - Supply: 1.65V~5.5V
Propagation Delay: 3.8ns@5.5V,50pF
Output Logic Level - Low: 70mV~450mV;120mV~300mV;170mV~400mV;330mV~550mV;390mV~550mV
Features: Local shutdown mode;Overvoltage-tolerant input
Input Logic Level - Low: 700mV;800mV
Operating Temperature: -40℃~+125℃
Input Logic Level - High: 1.7V;2V
Output Logic Level - High: 1.2V~1.54V;1.9V~2.15V;2.2V~2.5V;2.3V~2.62V;3.8V~4.11V
Quiescent Current(Iq): 4uA
Current - Output High(IOH): 24mA
Number of Channels: 1;3
Current - Output Low(IOL): 24mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.044 g

Overview

The EM74LVC1G11 is a single 3-input AND gate. The inputs can be driven by 3.3V or 5V devices. This feature allows the device to be used as a level translator in mixed 3.3V and 5V applications. Schmitt-trigger action on all inputs makes the circuit tolerant of slower input rise and fall times. The device is fully specified for partial power-down applications using IOFF. The IOFF circuit disables the outputs, preventing damaging backflow current when the device is powered down.

Key features

Wide supply voltage range: 1.65V to 5.5V
High noise immunity
±24 mA output drive capability (VCC = 3.0V)
CMOS low power consumption
Direct TTL-level interface compatible
Input overvoltage tolerance up to 5.5V
IOFF circuitry supports partial power-down mode operation
Latch-up performance exceeds 100 mA
Compliant with JEDEC standards: JESD8-7 (1.65V to 1.95V), JESD8-5 (2.3V to 2.7V), JESD8C (2.7V to 3.6V), JESD36 (4.5V to 5.5V)
ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3B exceeds 8000 V; MM JESD22-A115C Class C exceeds 550 V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
Multiple package options
