FRTC1339M

The FRTC1339M serial real-time clock is a low-power clock/calendar device featuring two programmable daily alarms and a programmable square-wave output. Address and data are transferred serially via a two-wire bidirectional bus. The clock/calendar provides seconds, minutes, hours, day of week, date, month, and year information. End-of-month dates are automatically adjusted for months with fewer than 31 days, including leap year correction. The clock operates in 24-hour or 12-hour format with an AM/PM indicator. The FRTC1339M incorporates a power-sense circuit that detects power failures and automatically switches to the backup supply.

Applications

• Handheld devices (GPS, POS terminals)
• Consumer electronics (set-top boxes, digital video recorders, networking equipment)
• Office equipment (fax machines/printers, copiers)
• Medical (blood glucose meters, pill dispensers)
• Telecommunications (routers, switches, servers)

Key features

• Real-time clock (RTC) counts seconds, minutes, hours, day of week, date, month, and year with leap year compensation valid through 2100
• Two-wire serial interface
• Two programmable daily alarms
• Programmable square-wave output
• Oscillator stop flag
• Automatic power-fail detect and switch circuitry
• Trickle charge capability
• Operating temperature: -40 ~ 125°C
