GREENMICRO

GM317AEMP

1.2V~37V Positive Adjustable SOT-223 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators

SOT-223RoHSActive

Manufacturer: GREENMICRO
Manufacturer part #: GM317AEMP
Store part #: C49329011
Package / case: SOT-223
Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

4,275 in stock

#C49329011

Stock & price checked 7 days ago

Quantity	Unit price	Pack price
5+	₹10.24	₹51.20
50+	₹9.00	₹450.00
150+	₹8.37	₹1,255.50
500+	₹7.90	₹3,950.00
2,500+	₹7.53	₹18,825.00
5,000+	₹7.34	₹36,700.00

Quantity (min 5, multiples of 5)

5 × ₹10.24

₹51.20

excl. GST

₹60.42 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

GM317AEMP

₹51.20 for 5 + GST

Specifications

Output Voltage: 1.2V~37V
Number of Outputs: 1
Operating Temperature: -20℃~+125℃@(Ta)
Output Configuration: Positive
Output Current: 1.5A
Operating Voltage: 40V
Output Type: Adjustable

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.224 g

Overview

The 317 device is an adjustable 3-terminal positive voltage regulator capable of supplying more than 1.5A over an output voltage range of 1.25V to 37V. The device features an extremely low standby current with a typical value of 1.5mA. It requires only two external resistors to set the output voltage, with a typical line regulation of 1mV and a typical load regulation of 7mV. The device is widely applicable for programmable output regulation and on-board local regulation. By connecting a fixed resistor between the adjustment pin and the output pin, it can also be used as a precision current regulator. An optional output capacitor can be used to improve transient response.
