GR2833M
SOP-16 Motor Drivers, Controllers
Dedicated stepper motors and IR-Cut Removable driver integrated circuits
- Manufacturer
- GR
- Manufacturer part #
- GR2833M
- Store part #
- C18164468
- Package / case
- SOP-16
- Category
- Motor Drivers, Controllers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,315 in stock
#C18164468
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹23.96 | ₹119.80 |
| 50+ | ₹21.02 | ₹1,051.00 |
| 150+ | ₹19.77 | ₹2,965.50 |
| 500+ | ₹18.20 | ₹9,100.00 |
| 2,500+ | ₹17.50 | ₹43,750.00 |
| 5,000+ | ₹17.09 | ₹85,450.00 |
5 × ₹23.96
₹119.80
excl. GST
₹141.36 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
GR2833M
₹119.80 for 5 + GST
Specifications
- Drive Type
- Bipolar Driver
- Technology
- No
- Interface
- I2C;Parallel
- Operating Temperature
- -45℃~+85℃
- Output Current
- 400mA
- Control Voltage
- 2.8V~5.5V
- Motor Drive Voltage(Vm)
- 2.8V~5.5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.19 g
Overview
GR2833M is a dedicated stepper motor and IR-Cut Removable driver IC. It is compatible with I²C bus input, featuring eight parallel outputs for stepper motor control and two mutually exclusive outputs for IR-Cut motor driving. This serial-in parallel-out architecture conserves MCU output port resources, reduces PCB routing area, and improves design efficiency. The GR2833M can drive two 4-phase stepper motors, eight relays, or be used in other applications such as LED large-display driving.
Key features
- Supply voltage: 3V ~ 6V
- I²C bus compatible
- Maximum output current: 400mA, Ta = 25°C
- 8-channel parallel output, 2-channel IR-Cut mutually exclusive output
- Low power consumption: typical 0uA
- Package: SOP16, QFN16
