HGSEMI

HGOP27BDQ3/TR

30uV 28nA 100dB 3.81mA 8MHz DFN-8(3x3) Instrumentation, Op Amps, Buffer Amps

DFN-8(3x3)RoHSActive

Manufacturer: HGSEMI
Manufacturer part #: HGOP27BDQ3/TR
Store part #: C52953091
Package / case: DFN-8(3x3)
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,000 in stock

#C52953091

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹98.06	₹98.06
10+	₹79.31	₹793.10
30+	₹70.05	₹2,101.50
100+	₹60.78	₹6,078.00
500+	₹55.21	₹27,605.00
1,000+	₹52.32	₹52,320.00

Quantity (min 1)

1 × ₹98.06

₹98.06

excl. GST

₹115.71 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 5,000 per reel

HGOP27BDQ3/TR

₹98.06 for 1 + GST

Specifications

Vos - Input Offset Voltage: 30uV
Input Offset Current(Ios): 8nA
Operating Temperature: -40℃~+85℃
Ib - Input Bias Current: 28nA
Common Mode Rejection Ratio(CMRR): 100dB
Input Offset Voltage Drift(Vos TC): 1.8uV/℃
Quiescent Current: 3.81mA
Gain Bandwidth Product: 8MHz
Input Voltage Noise Density: 3.2nV/√Hz@1kHz

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 5,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.06 g

Overview

HGOP27 is a high-precision op-amp with a maximum offset voltage of 150uV and a gain of 200V/mV. It is therefore particularly well-suited for instrumentation and similar applications. The device features a wide input voltage range (±13V) and a CMRR exceeding 100dB, maintaining excellent linearity and gain accuracy even in high closed-loop gain circuits.
